Automatic Memory Leak Destroyer

this system is too cool to be real!!

Wow, this is probably the greatest thing to happen for GUI users in the history of WC3 modding. My hat is off to you

You shall soon become a god amongst GUI users

Too bad it didn't come out years ago.

This is an Automatic memory Leak Destroyer!
It catches all the memory leaks you cause by using locations/groups or effects in GUI and destroys them automatically.

There is just one thing you have to care about when using this:
Each variable that you use, filled with a group, a location or an effect, that has
to be filled for more than CLEAN_UP_INTERVAL seconds, has to be protected with
a simple function:

call ProtectHandle(udg_###)

where ### stands for the variable name.

Note: This gives DoNothing a sense.
When you call DoNothing, the destroy thread is started and the caught data are destroyed after CLEAN_UP_INTERVAL seconds, ignoring if the number of caught handles is bigger than MIN_LEAK_NUMBER.
Normally you never have to use it, but you can do so.

So to make it clear:
Memory leaks caused by things like this:



are cleared automatically!
And not only things like this, all leaks.
This can also be used as an addition to your own leak cleaning, if you forgot something.
It wont break, when you destroy your leaks on your own


This is the code:

JASS:
library MemoryLeakHelper initializer Init requires Table
// ==================================
// Give credits to Mr.Malte when used!
//===========================================================================
// Information:
//==============
//
//  There are things called 'memory Leaks'. When you create a group or use a location
//  without destroying it, you will cause lag that stays in the whole game.
//  If you implement this library into your map it will automatically fix a big part
//  of those memory leaks, so reduce the lag extremely.
//  This should mainfully be used by GUI-users because the system is designed for them.
//
//  Of course no system can work totally automatically.
//  But there is only one thing you have to do in order to prevent bugs:
//  If you make groups or locations that have to be filled for more than CLEAN_UP_INTERVAL seconds
//  you have to save them with the code:
//
//  call ProtectHandle(XXX)
//
//  Where XXX is filled with your variable. Otherwise that variable gets destroyed
//  automatically. You can also fill in XXX with
//
//  GetLastCaughtHandle()
//
//  But if you save the things in a variable, I'd recommend to directly put the
//  variable into the brackets. Note: GUI variables have the prefix 'udg_' in JASS.
//
//     This gives the 'Do Nothing' function in GUI a sense!
//     When you call DoNothing, all data that were caught by this system
//     will be destroyed in CLEAN_UP_INTERVAL seconds, ignoring how big
//     the number of caught handles is. This will not work, if the system is
//     already cleaning up.
//===========================================================================
// Implementation:
//===============
//
//  The easiest thing is to directly implement this thing into your map, when you start making
//  it, so you don't have to look over your globals and use ProtectHandle on them.
//  These are the steps you have to do to clear the memory leaks:
//
//  1. Download a tool called 'JassNewGen', and unpack it somewhere. You need that
//     edit to use this tool. The 'JassNewGen' is used very commonly and offers other
//     nice features. You can find it at:
//     [url]http://www.wc3c.net/showthread.php?t=90999[/url]

//  2. Make a new trigger, and convert it to custom text. Insert everything
//     the library contains into that trigger.
//
//  3. Download a system called 'Table' from this link:
//     [url]http://www.wc3c.net/showthread.php?t=101246[/url]
//     Do the same installation stuff for 'Table' as for this system.
//
//  4. Save your map and enjoy :-)
//
//  Note: Instead of doing 2 and 3 you can also copy and paste the folder 'MemoryLeakHelper'
//        from the example map.
//===========================================================================
// How bad are memory leaks?
//==========================
//  If you don't remove memory leaks, they suck memory:
//
//  Location:  0.361 kb
//  Group:     0.62 kb + 0.040 kb for each unit in the group.
//  Effect:    11.631 kb
//
// Both, locations and groups are used very frequently. So when you don't fix those memory leaks,
// you will experience lag.

//        When you want to see, how useful this is for your map, implement it
//        and write 'call DisplayLeaks()' into a custom script that is fired when
//        they game ends.
//===========================================================================
// Changelog:
//===========
// v1.00 --- first version
// v1.01 --- able to detect special effects, too now.
// v1.02 --- made the system safer and reduced the number of variables to protect greatly.
// v1.03 --- Gave a sense to 'DoNothing'* GUI function and made the Pass Data part
//           more accurate, so the time until data get destroyed are much more explicit
//           now.
//
// *if you don't want it to be hooked, put // before line 341.
//===========================================================================
// FAQ:
// ====
//  1. Why don't you hook functions like GetLocationX or the ForGroup without BJ?
//
//      Answer: Well, in jass you would never destroy groups, rather have one global group
//              and clear/recycle it. But GUI always creates new groups with the functions.
//              So actually, jass groups don't have to be destroyed.
//              And special effects are mostly instantly destroyed and locations are never used.
//              So I don't want to endanger breaking jass systems, I rather make it for GUI, where it is
//              really useful and neccessary
//
//  2. Why should I protect my variables instead of killing my leaks?
//
//      Answer: In GUI, unitgroup effect and location variables are actually just used
//              for destroying stuff. It is rare that you really want to keep the groups.
//              So in fact, it is like one-hundred times less frequent that you want to keep
//              your data instead of destroying it.
//
//  3. I can't use jass. How can this system be useful for me?
//
//      Answer: This system works mainly automatically; You just have to use jass very rarely (and then a simple function).
//              The functions you need are:
//
//                  ProtectVariable(udg_###)
//                  GetLastCaughtHandle()
//
//              where ProtectVariable saves something you want to keep from getting destroyed. Just replace ### with your
//              variable name. NOTE: You don't have to protect the variable, when you want to keep the data inside less than
//              CLEAN_UP_INTERVAL seconds.
//
//              and where GetLastCaughtHandle responses to the handle* that was used lastly.
//              That can be for example the point where you just spawned a unit.
//
//      * 'handle' means a specialeffect, a location or a unitgroup
//
//  4. If you give functions like 'DelayMMH', why don't you add functions like 'Disable/EnableMMH'?
//
//      Answer: Well, I want to protect the user. You do not need Disable/Enable functions.
//              To me the danger is too big, that you forget to activate it again or do
//              something like that. DelayMMH is totally enough if you don't want this system
//              to affect the code that comes next. Also that prevents, that there are
//              spells like 'Trojan Horses' that get too much access to this and can
//              change it's infrastructure.
//
//===========================================================================
// Functions:
//==========
// ProtectHandle              : Saves a handle from getting destroyed
// ProtectVariable            : Same.
// DoNothing()                : Destroys all data caught by the system right now in X seconds.
// DelayMMD()                 : Stops the system working until the trigger ends/next wait *
//
// * This is as fast as an automatic memory leak destroyer can get. Why should
// you want to disable the system? Because it offers the possibilty to make things
// more efficient. I don't want to say, this is unefficient, because it is not.
// But this will destroy leaks like 10% slower.
//
//===========================================================================


    globals
        // The system fires when you do something that creates a leak.
        // The data that cause leak are saved in a variable then.
        // And every CLEAN_UP_INTERVAL seconds those data are destroyed.
        // This shouldn't be too high, or too low.
        private constant real CLEAN_UP_INTERVAL = 20.
        // If this is set to true, the system will work more slowly (but you wont notice)
        // and count, how much memory this system was able to save.
        // This value is display by the function DisplayLeaks() then.
        // WARNING: This sucks a lot of performance. I would ONLY use it when you want
        // to test, if this is useful for your map. Later set it to false.
        private constant boolean DISPLAY_SAVED_MEMORY = false
        // The Data are only cleaned up, when that many handles were caught
        private constant integer MIN_LEAK_NUMBER = 1750
        // How often are data passed to the destroyer?
        // Leaks stay for a random time between CLEAN_UP_INTERVAL and CLEAN_UP_INTERVAL+PASS_INTERVAL
        // in the game
        private constant real PASS_INTERVAL = 2.5
    endglobals

    globals
        private HandleTable IndexData
        private HandleTable IsSaved

        //! textmacro MemoryLeakVars takes NAME, TYPE
        private integer Caught$NAME$Leaks = 0
        private $TYPE$ array $NAME$LeakData
        private integer $NAME$DestroyCount = 0
        private $TYPE$ array $NAME$DestroyData
        //! endtextmacro
        //! runtextmacro MemoryLeakVars("Location","location")
        //! runtextmacro MemoryLeakVars("Effect","effect")
        //! runtextmacro MemoryLeakVars("Group","group")


        private integer DestroyedLeaks = 0
        private integer CaughtLeaks = 0
        private integer DestroyedLeaksUser = 0
        private handle LastCaught
        private timer PassTimer = CreateTimer()
        private timer CleanTimer = CreateTimer()
        private timer DelayTimer = CreateTimer()
        private boolean IsDestroying = false
        private real SavedMemory = 0.
        private real LastCheckedGroupMemoryUsage = 0.
        private boolean DestroyThreadRunning = false
        private boolean Disabled = false

        // These values were found out in a big leak test by gekko.
        private constant real LOCATION_MEMORY_USAGE        = 0.361
        private constant real GROUP_MEMORY_USAGE           = 0.62
        private constant real GROUP_UNIT_MEMORY_USAGE      = 0.040
        private constant real EFFECT_MEMORY_USAGE          = 11.631
        private constant real REMOVED_EFFECT_MEMORY_USAGE  = 0.066
    endglobals

    // ======================================
    // ============= Basic Code =============
    // ======================================

    function GetLastCaughtHandle takes nothing returns handle
        return LastCaught
    endfunction

    function ProtectHandle takes handle h returns nothing
        set IsSaved[h] = 1
    endfunction

    function ProtectVariable takes handle h returns nothing
        set IsSaved[h] = 1
    endfunction

    private function EnableMMH takes nothing returns nothing
        set Disabled = false
    endfunction

    function DelayMMH takes nothing returns nothing
        set Disabled = true
        call TimerStart(DelayTimer,0.00,false,function EnableMMH)
    endfunction

    function DisplayLeaks takes nothing returns nothing
        call ClearTextMessages()
        call BJDebugMsg("======= MemoryLeakHelper =======")
        call BJDebugMsg("Destroyed Leaks: "+I2S(DestroyedLeaks))
        call BJDebugMsg("Destroyed Leaks by user: "+I2S(DestroyedLeaksUser))
        call BJDebugMsg("Percentage System: "+R2S(I2R(DestroyedLeaks)/I2R(DestroyedLeaks+DestroyedLeaksUser)*100.)+"%")
        call BJDebugMsg("Percentage User: "+R2S(I2R(DestroyedLeaksUser)/I2R(DestroyedLeaks+DestroyedLeaksUser)*100.)+"%")
        call BJDebugMsg("Leaks until next destroy: "+I2S(MIN_LEAK_NUMBER-CaughtLeaks))
        call BJDebugMsg(" === In Destroy Queue === ")
        call BJDebugMsg("   Group Leaks: "+I2S(GroupDestroyCount))
        call BJDebugMsg("   Location Leaks: "+I2S(LocationDestroyCount))
        call BJDebugMsg("   Effect Leaks: "+I2S(EffectDestroyCount))
        call BJDebugMsg(" === Not in Destroy Queue yet === ")
        call BJDebugMsg("   Group Leaks: "+I2S(CaughtGroupLeaks))
        call BJDebugMsg("   Location Leaks: "+I2S(CaughtLocationLeaks))
        call BJDebugMsg("   Effect Leaks: "+I2S(CaughtEffectLeaks))
        call BJDebugMsg("Time until next PassSequence: "+I2S(R2I(TimerGetRemaining(PassTimer)+0.5))+" seconds.")
        call BJDebugMsg(" ")
        if DISPLAY_SAVED_MEMORY then
            call BJDebugMsg("All in all the MemoryLeakHelper could release "+R2S(SavedMemory)+" kb of memory.")
        endif
        call BJDebugMsg("================================")
    endfunction

    private function GroupGetMemoryUsageEnum takes nothing returns nothing
        set LastCheckedGroupMemoryUsage = LastCheckedGroupMemoryUsage + GROUP_UNIT_MEMORY_USAGE
    endfunction

    function GroupGetMemoryUsage takes group g returns real
        set LastCheckedGroupMemoryUsage = 0.
        call ForGroup(g,function GroupGetMemoryUsageEnum)
        return LastCheckedGroupMemoryUsage + GROUP_MEMORY_USAGE
    endfunction

    //! textmacro ResponseOnLeak takes NAME, VALUE
    private function Catch$NAME$ takes $VALUE$ l returns nothing
        set LastCaught = l

        if Disabled then
            return
        endif

        if IndexData.exists(l) == false then
            //call BJDebugMsg("Caught $NAME$")
            set Caught$NAME$Leaks = Caught$NAME$Leaks + 1
            set $NAME$LeakData[Caught$NAME$Leaks] = l
            set IndexData[l] = Caught$NAME$Leaks
        endif
    endfunction

    private function AddTo$NAME$DestroyQueue takes $VALUE$ l returns nothing
        set $NAME$DestroyCount = $NAME$DestroyCount + 1
        set $NAME$DestroyData[$NAME$DestroyCount] = l
        set IndexData[l] = $NAME$DestroyCount*-1 // Put his to negative, so we know that this is used in the DestroyQueue now.
    endfunction

    private function Release$NAME$ takes $VALUE$ l returns nothing
        local integer index
        if IsDestroying == false and IndexData.exists(l) then
            set index = IndexData[l]
            // If this is true, the index wasn't put to a destroy queue yet.
            if index > 0 then
                set $NAME$LeakData[index] = $NAME$LeakData[Caught$NAME$Leaks]
                set Caught$NAME$Leaks = Caught$NAME$Leaks - 1
            else
                set index = index * -1
                set $NAME$DestroyData[index] = $NAME$DestroyData[$NAME$DestroyCount]
                set $NAME$DestroyCount = $NAME$DestroyCount - 1
            endif
            call IndexData.flush(l)
            set DestroyedLeaksUser = DestroyedLeaksUser + 1
        endif
    endfunction
    //! endtextmacro
    //! runtextmacro ResponseOnLeak("Location","location")
    //! runtextmacro ResponseOnLeak("Group","group")
    //! runtextmacro ResponseOnLeak("Effect","effect")

    private function DestroyMemoryLeaks takes nothing returns nothing
        set IsDestroying = true

        //call BJDebugMsg("DESTROYING Memory Leaks")
        //! textmacro DestroyLeaks takes NAME, DESTROYCALL, MEMORYUSAGE
        set DestroyedLeaks = DestroyedLeaks + $NAME$DestroyCount
        loop
            exitwhen $NAME$DestroyCount == 0

            if DISPLAY_SAVED_MEMORY then
                set SavedMemory = SavedMemory + $MEMORYUSAGE$
            endif

            call $DESTROYCALL$($NAME$DestroyData[$NAME$DestroyCount])
            call IndexData.flush($NAME$DestroyData[$NAME$DestroyCount])
            set $NAME$DestroyCount = $NAME$DestroyCount - 1
        endloop
        //! endtextmacro
        //! runtextmacro DestroyLeaks ("Group","DestroyGroup","GroupGetMemoryUsage(GroupDestroyData[GroupDestroyCount])")
        //! runtextmacro DestroyLeaks ("Location","RemoveLocation","LOCATION_MEMORY_USAGE")
        //! runtextmacro DestroyLeaks ("Effect","DestroyEffect","EFFECT_MEMORY_USAGE")

        set IsDestroying = false
        set DestroyThreadRunning = false
        //call StartPassTimer.execute() // Strange. This causes bugs sometimes and the function isn't called
        // This is slower, but safe.
        call ExecuteFunc("StartPassTimer")
    endfunction

    function StartDestroyThread takes nothing returns nothing
        if DestroyThreadRunning == false then
            set DestroyThreadRunning = true
            call TimerStart(CleanTimer,CLEAN_UP_INTERVAL,false,function DestroyMemoryLeaks)
            call PauseTimer(PassTimer)
        endif
    endfunction

    hook DoNothing StartDestroyThread

    // We want that the user doesn't have to protect too many variables, but all the variables that are filled longer
    // than CLEAN_UP_INTERVAL seconds. But what, when the handle thing is put into the destroy stack and the next destroy is
    // in 5 seconds, because the last one was 15 seconds ago? We can simply avoid something like that by using a 2-step-system
    // that goes sure, the handle is only destroyed when it passed the CLEAN_UP_INTERVAL twice.
    // Having two kinds of variables is simply easier and more efficient than having another variable that refers to
    // how many times the handle passed the timer; If it isn't passed/cleared in the Interval then, we can't loop
    // that easily through the data and we'd have to fix gaps later; That would suck a lot of performacne.
    private function PassMemoryLeaks takes nothing returns nothing
        //call BJDebugMsg("PassMemoryLeaks")
        //! textmacro PassLeaks takes NAME
        set CaughtLeaks = CaughtLeaks + Caught$NAME$Leaks
        //call BJDebugMsg("Caught $NAME$s: "+I2S(Caught$NAME$Leaks))
        loop
            exitwhen Caught$NAME$Leaks < 1
            if IsSaved.exists($NAME$LeakData[Caught$NAME$Leaks]) == false and $NAME$LeakData[Caught$NAME$Leaks] != null then
                call AddTo$NAME$DestroyQueue($NAME$LeakData[Caught$NAME$Leaks])
            endif
            set $NAME$LeakData[Caught$NAME$Leaks] = null
            set Caught$NAME$Leaks = Caught$NAME$Leaks - 1
        endloop
        //! endtextmacro
        //! runtextmacro PassLeaks ("Group")
        //! runtextmacro PassLeaks ("Location")
        //! runtextmacro PassLeaks ("Effect")

        if CaughtLeaks > MIN_LEAK_NUMBER then
            set CaughtLeaks = 0
            //call BJDebugMsg("Caught Leaks: "+I2S(MIN_LEAK_NUMBER))
            //call BJDebugMsg("Now start Destroy Timer")
            set DestroyThreadRunning = true
            call TimerStart(CleanTimer,CLEAN_UP_INTERVAL,false,function DestroyMemoryLeaks)
            // We have to pause this timer a bit; Otherwise it would break the CLEAN_UP_INTERVAL rule.
            call PauseTimer(PassTimer)
        endif

    endfunction

    // =================================
    // ============= Usage =============
    // =================================

    private function PP takes location source, real dist, real angle returns nothing
        call CatchLocation(source)
    endfunction

    private function CU takes integer count, integer unitId, player p, location l, real face returns nothing
        call CatchLocation(l)
    endfunction

    private function IPO takes unit k, string order, location l returns nothing
        call CatchLocation(l)
    endfunction

    private function SUP takes unit who, location l returns nothing
        call CatchLocation(l)
    endfunction

    private function SUF takes unit who, location l, real dur returns nothing
        call CatchLocation(l)
    endfunction

    private function GUR takes real radius, location l, boolexpr filter returns nothing
        call CatchLocation(l)
    endfunction

    private function CUF takes integer count, integer unitId, player whichPlayer, location loc, location lookAt returns nothing
        call CatchLocation(loc)
        call CatchLocation(lookAt)
    endfunction

    hook PolarProjectionBJ PP
    hook CreateNUnitsAtLoc CU
    hook CreateNUnitsAtLocFacingLocBJ CUF
    hook IssuePointOrderLocBJ IPO
    hook SetUnitPositionLoc SUP
    hook SetUnitFacingToFaceLocTimed SUF
    hook GetUnitsInRangeOfLocMatching GUR

    hook RemoveLocation ReleaseLocation


    private function FG takes group g, code callback returns nothing
        call CatchGroup(g)
    endfunction

    hook ForGroupBJ FG // :D This should catch all GUI usages for groups.
    hook GroupPickRandomUnit CatchGroup
    hook CountUnitsInGroup CatchGroup

    hook DestroyGroup ReleaseGroup

    private function ASETU takes string bla, widget d, string blu returns nothing
        // We can not catch THIS effect, but the effect that was created before.
        // So we can destroy all SpecialEffects excpet one.
        call CatchEffect(GetLastCreatedEffectBJ())
    endfunction

    private function ASE takes location where, string modelName returns nothing
        call CatchLocation(where)
        call CatchEffect(GetLastCreatedEffectBJ())
    endfunction

    hook AddSpecialEffectLocBJ ASE
    hook AddSpecialEffectTargetUnitBJ ASETU
    hook DestroyEffect ReleaseEffect
    hook DestroyEffectBJ ReleaseEffect

    // When I want to make the timer run the PassMemoryLeaks things, I have to use an .execute command which requires an extra func.
    function StartPassTimer takes nothing returns nothing
        //call BJDebugMsg("Restarting PassTimer")
        call TimerStart(PassTimer,PASS_INTERVAL,true,function PassMemoryLeaks)
    endfunction

    private function Init takes nothing returns nothing
        set IndexData = HandleTable.create()
        set IsSaved = HandleTable.create()
        call StartPassTimer()
    endfunction
endlibrary

This uses Table by Vexorian!

Keywords:
memory, leaks, vjass, mui, gui, system, ,
Contents

MemoryLeakHelper (Map)

Reviews
10:10, 26th Sep 2009 The_Reborn_Devil: The code looks good and I couldn't see any leaks or other problems. This is definitely useful for GUI users. Approved Rating: Recommended I might change it to Highly Recommended.
Level 11
Joined
Nov 4, 2007
Messages
337
To all my opponents!
I prove with speed tests that this is faster than the natives!
It improves the speed of your spells!

CatchLocation takes 21 nanoseconds for an execution
RemoveLocation takes 24.

The DestroyFunctions take a lot more time, but they are called rarely.
You will not notice lag when they're called (like everx 120 seconds).

Level 6
Joined
Jun 1, 2008
Messages
95
Why are you all arguing on this? There are people who just started making maps and have not learnt how to remove leaks and may think this system is useful. If it is not useful to you, dont use it. Dont say that this system is useless to you blah blah blah because it may not be useful to you but it may be useful to others.

Level 9
Joined
Oct 11, 2009
Messages
477
When I execute the action call DisplayLeaks(), why does sometimes it show negative number of leaks?

And another question, is there an upcoming version of it in which it cleans string leaks?

Level 9
Joined
Oct 11, 2009
Messages
477
Yes, strings do leak but sucks memory not that big but if it becomes dominant in your map then it will cause continous lag in your map.

Last edited:
Level 2
Joined
Jun 1, 2017
Messages
16
Hello, I have some problem

this row: hook PolarProjectionBJ PP

error: missing define arguments

Level 38
Joined
Feb 27, 2007
Messages
4,951
The idea is great, but i couldn't import it in my map
While this could be relevant to your situation if you have failed to clean up location/group/etc. leaks in some of your map triggers, this type of system will absolutely not fix the 'locally declared handle variable' leaks that DSG and others have been talking about in other threads. This is explicitly for object data leaks, not object reference leaks.

It catered to the GUI users, and was never meant to be used by JASS or vJASS users. Even then, this hasn't been really frequented by users/guests, based on the statistics.

If the majority of the GUI users now are cleaning leaks up by themselves, or by the help of others (excluding linking to this), then I think it would be a sufficient point to raise when deprecating the resource (e.g. move to Substandard)

Top
