[GUI-Friendly] Trigger Logger System

Submitted by MyPad
This bundle is marked as approved. It works and satisfies the submission rules.
Thanks to Darkfang for the idea of creating this system for GUI users.

Welcome to the Trigger Logging System. This instrumentation based system can be used to debug trigger run order or nested trigger execution related errors. It offers the following features:

Trigger registration - A requirement in this system, this allows GUI and JASS users alike to register which triggers they want to monitor for execution. Only triggers which are registered can be monitored by the system.

Commands - Includes commands such as display, allow, and discard. You can type the name of a certain trigger after those commands in order to influence that trigger only. With these commands you can log the sequence of triggers being run and potentially observe if any unexpected nesting is occurring.​

Nested trigger execution is when the action of a trigger fires the event of another during execution. Since only 1 trigger thread can run at any time the causing trigger thread yields to allow the fired trigger thread to run fully before execution of the causing trigger thread can resume. This can be a common cause of hard to spot errors in GUI based maps. For example if both triggers use the same variables, such as variables holding temporary values, the fired trigger will overwrite the values while the causing trigger thread is still using them resulting in unexpected behaviour. Especially people new to Warcraft III map making might not be aware of all the actions which cause this and all the events they will fire.

It can also be used to detect if triggers are being run at unexpected times. For example if a trigger which is only intended to run once is being run several times.

This system is not a full blown trigger debugger. Its instrumentation only allows one to monitor the sequence triggers are run, and not the state of execution of trigger threads.



  • Code (vJASS):

    //! novjass
    Here are some available functions for JASSers:

    function DebugTrigger_SetTraceTrigger(trigger, boolean)
        If the trigger is in the system, this enables the tracing of the trigger in the evaluation
        of conditions.

        Also, if udg_DebugTrigger_Trace_DISABLE is true, the boolean flag determines the state of the
        trigger such that setting it to true would enable it, and the inverse is true.

    function DebugTrigger_SetWatchTrigger(trigger, boolean)
        If the trigger is in the system, this enables the watching of the trigger. This is enabled by
        default. When tracing is enabled, a trace message will be displayed.

    function DebugTrigger_WatchTrigger(trigger, string)
        If the trigger is in the system, an error will be displayed. Otherwise, if the name of the
        trigger, which the string represents, has already been cached, the system will display
        a notification, printing the new name of the trigger.

    The variable types enclosed in parentheses are the arguments of the function.
    //! endnovjass




  • Nearly all variables in the system are private. Here are some of the public variables, which you can tamper with:

    udg_DebugTrigger_ParamTrigger - The trigger which you want to affect.
    udg_DebugTrigger_ParamTriggerName - The assigned name of the trigger.
    udg_DebugTrigger_Instruction - The assigned instruction.

    You can assign the instruction variable into these values:

    0 - Makes the system watch the trigger above, with the assigned name.
    1 - Enables stack-tracing of the trigger. This will display info on every triggerevaluation.
    2 - Disables stack-tracing of the trigger. If udg_DebugTrigger_Trace_DISABLE is set to true,
    this also disables the trigger.

    There are helper variables specifically for that purpose. They are

    udg_DEBUGTRIGGER_REGISTER -> 0
    udg_DEBUGTRIGGER_TRACE -> 0
    udg_DEBUGTRIGGER_UNTRACE -> 0

    Once you have assigned the instruction and the parameter values, you can then execute the trigger
    <gen> Debug Trigger GUI.

  • Due to StringHash potentially causing collisions, the system might erroneously suffix a trigger name even when the name in question has only been introduced. Otherwise, the system is quite equipped to handle unusual test cases.

    When a certain trigger runs, the trigger conditions get fired first. All of the trigger conditions must return true in order for the trigger to proceed to the list of trigger actions. This system does not take into account the disparity between the number of executions and the number of evaluations.

  • Code (vJASS):

    //! novjass
    DebugTrigger_EnumPlayer
        An extra variable that has no other practical purpose after initialization.
        Consider this a free variable to use.

    DebugTrigger_ListenerCountKey = 0
        The key to the hashtable that stores the number of iterations a trigger
        has made.

    DebugTrigger_ListenerKey = 0
        The key to the hashtable that stores the flag that determines whether
        subsequent trigger iterations will be counted.

    DebugTrigger_ListenerTrace = 0
        The key to the hashtable that stores the flag that determines whether
        subsequent trigger iterations will display information.

    DebugTrigger_StringKey = 0
        The key ... that stores the indices of hashed strings.

    DebugTrigger_SubString[] = <Empty String>
        A string array variable that is used whenever <gen> Debug Trigger
        Core catches a player chat event. Indices used are 0, 1, and 2.

    DebugTrigger_TriggerHandle = 0
        The key ... that stores the triggers, bound to their indices.

    DebugTrigger_TriggerIndex = 0
        The key ... that stores the indices of the triggers, bound to their
        Handle id or Key of, in GUI.

    DebugTrigger_TriggerList = 0
        A static linked list that stores all the indices relevant to the system
        (e.g, indices generated by another system that are used to store
        registered triggers)

    DebugTrigger_TriggerKey = 0
        The key ... that acts as the allocator variable.

    DebugTrigger_TriggerNameKey = 0
        The key ... that stores the name of each and every trigger.

    DebugTrigger_TriggerNameCount = 0
        The key ... that stores the number of times the same trigger name
        has been used.
    //! novjass




    • v.1.0.0.0 - Introduction of the resource!
    • v.1.1.0.0 - Included some constants for readability purposes (mostly for GUI)
Contents

[GUI-Friendly] Trigger Debugger (Map)

Reviews
Dr Super Good
Comments and Suggestions: Potentially useful for people who are having problems with trigger run sequence or nested trigger execution related bugs. Can also be used to diagnose if triggers are firing unintentionally. Possibly some method of...
  1. Darkfang

    Darkfang

    Joined:
    Jun 25, 2008
    Messages:
    1,687
    Resources:
    199
    Models:
    1
    Icons:
    182
    Skins:
    11
    Maps:
    3
    Tutorials:
    2
    Resources:
    199
    How Is it implemented? Do you have to manually add each trigger or it does it all?

    Last edited: Jun 28, 2018
  2. MyPad

    MyPad

    Spell Reviewer

    Joined:
    May 9, 2014
    Messages:
    1,305
    Resources:
    7
    Models:
    1
    Icons:
    2
    Spells:
    3
    JASS:
    1
    Resources:
    7
    The user has to manually add the triggers which he/she wants to watch. That's one of the two drawbacks of the system, the other which is StringHash.

    Other than that, the instructions for both GUI and JASS users are already there. (Maybe it's incomplete, I'll update it tomorrow :con:)

  3. nedio95

    nedio95

    Joined:
    Mar 24, 2011
    Messages:
    1,055
    Resources:
    1
    Spells:
    1
    Resources:
    1
    @Darkfang , oh, well lad, I guess you are sorter ;)

    It looks like you have to do the following for EACH trigger you want to look at:
    • Register trigger
      • Events
        • Map Initialization
      • Conditions
      • Actions
        • -------------------------------------- TRIGGER 1 ------------------------------------
        • --------- The trigger you want to track
        • Set DebugTrigger_ParamTrigger = SomeTrigger
        • --------- String name of trigger you want to track
        • Set DebugTrigger_ParamTriggerName = "Whatever's easier for you"
        • --------- Instruction for the tracking
        • Set DebugTrigger_Instruction = 0 / 1 / 2
        • --------- Run registration
        • Trigger - Run Debug Trigger GUI
        • -------------------------------------- TRIGGER 2 --------------------------------------
        • --------- The second trigger you want to track
        • Set DebugTrigger_ParamTrigger = SomeTrigger2
        • --------- String name of second trigger you want to track
        • Set DebugTrigger_ParamTriggerName = "Meh"
        • --------- Instruction for the tracking
        • Set DebugTrigger_Instruction = 0 / 1 / 2
        • --------- Run registration
        • Trigger - Run Debug Trigger GUI


    regards
    -Ned

  4. MyPad

    MyPad

    Spell Reviewer

    Joined:
    May 9, 2014
    Messages:
    1,305
    Resources:
    7
    Models:
    1
    Icons:
    2
    Spells:
    3
    JASS:
    1
    Resources:
    7
    Very well said, @nedio95.

    However, the other instructions, which are 1 and 2 do not need ParamTriggerName to be specified in order to work in GUI.

    I'll add enum variables specifically for the purpose of GUI usage.

  5. Dr Super Good

    Dr Super Good

    Spell Reviewer

    Joined:
    Jan 18, 2005
    Messages:
    25,543
    Resources:
    3
    Maps:
    1
    Spells:
    2
    Resources:
    3
    So how does this help with debugging triggers? What are some use cases where this system might help a user fix a bug?

  6. MyPad

    MyPad

    Spell Reviewer

    Joined:
    May 9, 2014
    Messages:
    1,305
    Resources:
    7
    Models:
    1
    Icons:
    2
    Spells:
    3
    JASS:
    1
    Resources:
    7
    It tells the user which triggers are running should the triggers be registered into the system. A case might be a new event running while another is still running, which might overwrite variables used by the previous event, causing unintended behavior.

  7. Dr Super Good

    Dr Super Good

    Spell Reviewer

    Joined:
    Jan 18, 2005
    Messages:
    25,543
    Resources:
    3
    Maps:
    1
    Spells:
    2
    Resources:
    3
    I do not think debugger is the right word for this. It is more a trigger execution logger since it is missing practically every feature one would expect in a decent debugger such as stack traces, variable inspection, break points, stepped execution, etc.

    One concern is that the sort of person who runs into bugs caused by trigger stacking issues is the sort of person who would not know that a system like this could help detect them.

  8. MyPad

    MyPad

    Spell Reviewer

    Joined:
    May 9, 2014
    Messages:
    1,305
    Resources:
    7
    Models:
    1
    Icons:
    2
    Spells:
    3
    JASS:
    1
    Resources:
    7
    In such a case, would improving both the documentation and demonstration of the system in GUI be helpful for them?

    Interesting. I'm not quite sure if those can be implemented in this system without a substantial amount of user effort, so I'll rename them.

  9. Dr Super Good

    Dr Super Good

    Spell Reviewer

    Joined:
    Jan 18, 2005
    Messages:
    25,543
    Resources:
    3
    Maps:
    1
    Spells:
    2
    Resources:
    3
    The sort of person who could benefit from this would likely be unaware it exists. The sort of person who is aware this exists does not need this as they are well aware of how global variables work and so actively avoid overlapping global variable usage and can manually notice if any does occur without the need for wiring in instrumentation. Then the people beyond that start to use JASS with local variables which do not allow for overlapping usage of temporary storage.

    Then let us not forget that this is quite confusing to use. One has to enter text commands and get listings and test out which has to be looked through in message logs (not possible in multiplayer) due to the potential volume of data involved.
    You cannot implement such a thing. It has to be done at an engine level which is why no one has already, outside of abusing arbitrary code execution exploits in older versions of Warcraft III that have now been patched out.

    The main reason I suggest changing the name is because currently it is overselling itself. People might look at it and think it can do a lot more than it actually can. They might think it is some magic which will help them spot the logical error in their GUI triggers or see where things go wrong. In reality it just can be used to help detect trigger thread overlap or triggers firing which might help them if they know what they are doing.

  10. Pyrogasm

    Pyrogasm

    Joined:
    Feb 27, 2007
    Messages:
    2,892
    Resources:
    1
    Spells:
    1
    Resources:
    1
    IMO this is a big, important nail in the coffin on this resource, but who are we to decide that nobody would use something so it shouldn't exist? With a proper (non-deceptive) description this resource is just as valid as anything else in the Spells section (also, deceptively not all the things in it are spells for instance) that does a simple job efficiently.

  11. MyPad

    MyPad

    Spell Reviewer

    Joined:
    May 9, 2014
    Messages:
    1,305
    Resources:
    7
    Models:
    1
    Icons:
    2
    Spells:
    3
    JASS:
    1
    Resources:
    7
    The update to this resource will (hopefully) include indentation and order of execution of the debugged triggers.

  12. Dr Super Good

    Dr Super Good

    Spell Reviewer

    Joined:
    Jan 18, 2005
    Messages:
    25,543
    Resources:
    3
    Maps:
    1
    Spells:
    2
    Resources:
    3
    I have changed the submission name and description slightly so as to be less misleading to people. I think Trigger Logging System better describes what this does. Additionally I tried to clearly explain what it actually does and how it can be used to debug some specific kinds of errors.

    If you disagree with the changes or if they are inaccurate you are free to modify them.

  13. Dr Super Good

    Dr Super Good

    Spell Reviewer

    Joined:
    Jan 18, 2005
    Messages:
    25,543
    Resources:
    3
    Maps:
    1
    Spells:
    2
    Resources:
    3
    Comments and Suggestions:
    Potentially useful for people who are having problems with trigger run sequence or nested trigger execution related bugs. Can also be used to diagnose if triggers are firing unintentionally.

    Possibly some method of displaying the logged trigger information using a multiboard would be useful. Alternatively if file based IO is used one could write out the logs to files to be looked at outside the game.​

  14. Pyrogasm

    Pyrogasm

    Joined:
    Feb 27, 2007
    Messages:
    2,892
    Resources:
    1
    Spells:
    1
    Resources:
    1
    I like the multiboard suggestion for detailed trigger execution data.
