(DM42) (42S) Length of the curve of a function

01262020, 05:40 PM
(This post was last modified: 01262020 05:51 PM by rawi.)
Post: #1




(DM42) (42S) Length of the curve of a function
The following little program computes the length of the curve of a function using the integration function.
Application: The function of which you want to get the curve length has to be programmed under the label "FU". I use as an example the function y=4x²x3. But you can replace it by any other function as long as it can be differentiated within the limits you use. Press the integration key. Select "CLENT" as the integration program. Select "X" for the variable. Put in the area of the function for which you want to have the length of the curve using LLIM and ULIM. Put in the accuracy you want ("ACC") and press the integration key. For example using 0.75 as LLIM and 1 as ULIM (for these x the function 4x²x3 is zero, but this is not necessary) and an accuracy of .0001 you get as a result 6.5177 which is the exact value within the limits of the accuracy used. Enjoy! Best Raimund { 53Byte Prgm } LBL "CLENT" MVAR "X" RCL "X" 1E4  XEQ "FU" STO11 RCL "X" 1E4 + XEQ "FU" RCL11  2E4 ./. X² 1 + SQRT RTN END { 20Byte Prgm } LBL"FU" MVAR "X" ENTER X² 4 * X<>Y  3  RTN END
