DockingSystem v1.05.3

Submitted by Spellbound
This bundle is marked as approved. It works and satisfies the submission rules.
[​IMG]

Uses SmartTrack





Code (vJASS):

library DockingSystem /*

DockingSystem v1.05.3
By Spellbound

Special thanks to MyPad for finding out all the bugs and errors and helping me make this system better.

/*/
*==== DESCRIPTION ====*/*/

DockingSystem intends to replicate the Undead Haunted Gold Mine system by allowing you to
'dock' units (aka plugs) into a stationary unit, usually a building. The system comes with
the ability to move docking ports (aka sockets) so if you want to dock units to another
unit that's in motion, you may do that as well. This system comes with a lot of features
so take a moment and read through the API.


/*/
*==== INSTALLATION ====*/*/

• Copy-paste this trigger into your map.
• Copy-paste the required libraries into your map.
• The system is installed! Copy-paste the onDock Event trigger or make your own
  event trigger and start coding.

*/
requires /*

    */
SmartTrack   /* https://www.hiveworkshop.com/threads/smarttrack-v1-02-1.299957/
    */
Table        /* https://www.hiveworkshop.com/threads/snippet-new-table.188084/

    NB: SmartTrack requires a unit indexer that uses custom value. Either TriggerHappy's UnitDex or
    Bribe's GUI Unit Event/Unit Indexer  is recommended.

    Additionally, if you wish to dock units at different heights, you will need an Autofly
    library to allow ground units from changing height freely. The Autofly library in the
    DockingSystem demo map has been modified to work with UnitDex.

*/
optional /*

    */
WorldBounds /* https://github.com/nestharus/JASS/blob/master/jass/Systems/WorldBounds/script.j
    */
ListT       /* https://www.hiveworkshop.com/threads/containers-list-t.249011/

    WorldBounds is really not necessary at all, but if you have it in your map (which you generally
    should), the constant MAX_DISTANCE can use its variabled to calculate the longest map distance.

/*/
*==== API ====*/*/


/*SETUP and MODIFICATION________*/


DockingSystem.createStation( takes unit station, real socket_trigger_distance )
    This sets up a unit as the station that will then be given sockets for units to 'plug'
    into. Sockets are added separately.

DockingSystem.terminateStation( takes unit station )
    This terminates a station instance. Doing do will destroy all added sockets and undock
    any docked units.

DockingSystem.addSocket( takes unit station, real x, real y, real z, real facing_angle )
    Creates a socket and adds it to the desires station. Sockets can have any coordinates
    you desire them to have so they can be where ever you want them to be. The last argument,
    facing_angle, will determine the facing of the plug when it docks.

    IMPORTANT: This method will return the socket instance. If you wish to refer to this
    specific socket at a later date (eg: if you want to move it) you can do so by storing
    the instance in an integer variable.

DockingSystem.removeSocket( takes Socket socket_instance )
    Removes a socket from a station. Socket instances are obtained upon addSocket.

DockingSystem.moveSocket( takes Socket socket_instance, real x, real y, real z, real facing_angle )
    Alter the parameters of a socket. If a unit is currently docked in that socket, it will
    move with it. Socket instances are obtained upon addSocket.

DockingSystem.addSocketPointer( takes unit pointer, real range, boolean kill_pointer, Socket socket_instance )
    Creates a unit that acts as a pointer to a specific socket. When units dock into a station
    the chosen socket is done at random, but with a pointer you can tell the unit to dock into
    a specific socket. Pointers are proxies for the station itself with their own docking range,
    so placing one too far from the station will defacto teleport plugs around. If the
    socket_isntance is null, then they will teleport units to random open sockets. Socket
    instances are obtained upon addSocket.

DockinSystem.dock( takes unit plug, Socket socket_instance )
    Docks a unit into an empty plug. If the plug is currently occupied, nothing will happen.

DockinSystem.undock( takes unit plug )
    Undocks a unit from the station it is currently plugged into and fires an undocking event.
    Useful for when you want to handle the undocking manually.

DockingSystem.undockAll( takes unit station )
    Flushes all docked unit from a station. The sockets themselves remain intact.

RegisterNativeEvent( takes integer ev, code c )
    Sets up events for docking. The available events are EVENT_ON_PRE_DOCK, EVENT_ON_DOCK and
    EVENT_ON_UNDOCK. They should be fairly self-explanatory, but just in case I'm just
    projecting, here'
s what they do:

    EVENT_ON_PRE_DOCK  == BEFORE the plug has moved into place.
    EVENT_ON_DOCK      == After the plug has moved into place.
    EVENT_ON_UNDOCK    == When docking ends.
    EVENT_ON_REDOCK    == When a docked unit right-clicks its current station.
                       Can be used to issue error messages or reset animations.

RegisterIndexNativeEvent( takes integer playerNumber, integer ev, code c )
    Same as above, but player-specific.


/*PRE-DOCKING________*/

InterruptDocking()
    call this on EVENT_ON_PRE_DOCK to stop docking from happening.

SetDockingManual()
    call this on EVENT_ON_PRE_DOCK to stop automatic undocking triggers from being created.
    This means that ordering plugs to move or to stop will no undock them, so you will have
    to undock them manually.


/*UNDOCKING________*/

ResetUnitFlyHeight()
    call this on EVENT_ON_UNDOCK to reset a unit's flying height to its default value.


/*REFERRENCE________*/

call GetPlug()
    returns the plug during a docking event

call GetStation()
    returns the station during a docking event

call GetRandomSocket( takes unit station )
    returns the instance of a random socket.

call GetRandomSocketWithState( takes unit station, boolean is_socket_occupied )
    returns the instance of a socket. If the boolean is true, returns an occupied socket. If
    false, returns a vacant one.

call GetClosestSocketWithState( takes unit station, unit plug, boolean is_socket_occupied )
    returns the station'
s socket that is nearest to the plug.

call GetNumberOfSockets( takes unit station )
    returns the total number of sockets the station has.

call GetNumberOfOccupiedSockets( takes unit station )
    returns the total number of a station's occupied sockets.

call GetNumberOfEmptySockets( takes unit station )
    returns the total number of a station'
s vacant sockets.

call GetSocketPlug( takes Socket socket_instance )
    returns the unit currently docked in that socket. If the socket is empty, returns null.

call GetSocketFromPlug( takes unit plug )
    returns the socket in which a unit is plugged into.

call GetSocketX( takes Socket socket_instance )
    returns the x co-ordinate of the socket.

call GetSocketY(  takes Socket socket_instance )
    returns the y co-ordinate of the socket.

call GetSocketZ( takes Socket socket_instance )
    returns the z co-ordinate of the socket.

call GetSocketFacing( takes Socket socket_instance )
    returns the facing angle of the socket in degrees.

call GetSocketAngleFromStation( takes Socket socket_instance, real offset)
    returns the angle between the socket and the station in radians. This is useful for when
    you want to rotate the socket around the station with DockinSystem.moveSocket(), for
    example. The offset value is for when you want to make sure your sockets are referrencing
    the actual center of the station model as some models tend to offset their center by -16
    both on their x and y coordinate. If you station center appears off, try setting the offset
    to 16 or modifying the collision size of the station unit in the object editor.

call GetStationAngleFromSocket( takes Socket socket_instance, real offset)
    Same as above, but the returns the angle from the station to the socket.

*/

globals

    private DockingSystem array DS_Instance
    private integer array DS_SocketId
    private integer array DS_PlugCount

    private unit eventPlug = null
    private unit eventStation = null
    private boolean interruptDocking = false
    private boolean manualDocking = false

    integer EVENT_ON_PRE_DOCK
    integer EVENT_ON_DOCK
    integer EVENT_ON_UNDOCK
    integer EVENT_ON_REDOCK

    private real MAX_DISTANCE = 0.

endglobals


private struct Station
    static Table s
endstruct


// picks a socket at random and check if it's occupied or not depending on the state of the boolean
// LookForOccupiedSocket. If that first random try doesn't return anything, cycle through the rest
// of the sockets.
function GetRandomSocketWithState takes unit station, boolean lookForOccupiedSocket returns Socket

    local DockingSystem this = DS_Instance[GetUnitUserData(station)]
    local integer i = GetRandomInt(1, this.maxSockets)
    local integer iLoop = i
    local boolean firstPass = false
    local Socket s

    set Station.s = this.tableInstance
    set s = Station.s.integer[i]
    if lookForOccupiedSocket then
        if not (s.plug == null) then
            return s
        endif
    else
        if s.plug == null then
            return s
        endif
    endif

    // this loop starts from integer i. Since i is unlikely to be zero, the loop must cycle back
    // to 1 to ensure all sockets are checked.
    loop
        set iLoop = iLoop + 1
        if iLoop > this.maxSockets then
            set firstPass = true // this tells the loop that all values above integer i have already been checked
            set iLoop = 1 // this sets iLoop to the first socket and moves upwards from there.
        endif
        exitwhen (iLoop >= i and firstPass) // if this returns true, then all sockets have been checked.

        set s = Station.s.integer[iLoop]
        // (s.plug != null) returns true if the socket is occupied and false if empty.
        // Eg: if true, and LookForOccupiedSocket is also true, then it returns s.
        // If false, but LookForOccupiedSocket is true, the loop moves on to the next socket.
        if (s.plug != null) == lookForOccupiedSocket then
            return s
        endif
    endloop

    return 0
endfunction

function GetRandomSocket takes unit station returns Socket
    local DockingSystem this = DS_Instance[GetUnitUserData(station)]
    local Socket s
    set Station.s = this.tableInstance
    set s = Station.s.integer[GetRandomInt(1, this.maxSockets)]
    return s
endfunction

function GetSocketFromPlug takes unit u returns Socket
    return DS_SocketId[GetUnitUserData(u)]
endfunction

// since the purpose of this is to only find which Socket is closest, there is no need to
// perform a costly square root operation since (x < y) is the same as (x*x < y*y).
private function GetDistanceSquared takes real ax, real ay, real bx, real by returns real
    local real dx = bx - ax
    local real dy = by - ay
    return dx * dx + dy * dy
endfunction

// returns the Socket closest to the unit that's about to dock into a Station. This loop through all
// of a Station's sockets and, depending on whether you are looking for an occupied or unoccupied
// Socket, will return the one with the closest unit distance from the Plug.
function GetClosestSocketWithState takes unit station, unit plug, boolean lookForOccupiedSocket returns Socket
    local DockingSystem this = DS_Instance[GetUnitUserData(station)]
    local real tempDist
    local real maxRange = MAX_DISTANCE
    local real xPlug = GetUnitX(plug)
    local real yPlug = GetUnitY(plug)
    local integer i = 0

    local Socket closestSocket = 0
    local Socket s

    static if LIBRARY_ListT then

        local IntegerListItem node
        local IntegerListItem nodeNext

        if lookForOccupiedSocket then
            set node = this.busySockets.first
        else
            set node = this.freeSockets.first
        endif

        loop
            exitwhen node == 0
            set s = node.data
            set nodeNext = node.next

            set tempDist = GetDistanceSquared(s.x, s.y, xPlug, yPlug)
            if tempDist < maxRange then
                set maxRange = tempDist
                set closestSocket = s
            endif

            set node = nodeNext
        endloop

    else

        set Station.s = this.tableInstance

        loop
            set i = i + 1
            exitwhen i > this.maxSockets
            set s = Station.s.integer[i]

            if (s.plug == null) != lookForOccupiedSocket then
                set tempDist = GetDistanceSquared(s.x, s.y, xPlug, yPlug)
                if tempDist < maxRange then
                    set maxRange = tempDist
                    set closestSocket = s
                endif
            endif
        endloop

    endif

    return closestSocket
endfunction

function GetNumberOfSockets takes unit station returns integer
    return DS_Instance[GetUnitUserData(station)].maxSockets
endfunction

function GetNumberOfOccupiedSockets takes unit station returns integer
    return DS_PlugCount[GetUnitUserData(station)]
endfunction

function GetNumberOfEmptySockets takes unit station returns integer
    local integer id_S = GetUnitUserData(station)
    return DS_Instance[id_S].maxSockets - DS_PlugCount[id_S]
endfunction

function GetPlug takes nothing returns unit
    return eventPlug
endfunction

function GetStation takes nothing returns unit
    return eventStation
endfunction

function GetSocketPlug takes Socket s returns unit
    return s.plug
endfunction

function GetSocketX takes Socket s returns real
    return s.x
endfunction

function GetSocketY takes Socket s returns real
    return s.y
endfunction

function GetSocketZ takes Socket s returns real
    return s.z
endfunction

function GetSocketFacing takes Socket s returns real
    return s.facing
endfunction

function GetSocketAngleFromStation takes Socket s, real Offset returns real
    return Atan2((GetUnitY(s.station) + Offset) - s.y, (GetUnitX(s.station) + Offset) - s.x)
endfunction

function GetStationAngleFromSocket takes Socket s, real Offset returns real
    return Atan2(s.y - (GetUnitY(s.station) + Offset), s.x - (GetUnitX(s.station) + Offset))
endfunction

// Backward compatibility

function GetNumberOfSocketsWithState takes unit station, boolean occupied returns integer
if occupied then
    return GetNumberOfOccupiedSockets(station)
endif
return GetNumberOfEmptySockets(station)
endfunction

// Pre-dock actions

// Units will not automatically un-dock when this is called on pre-dock.
function SetDockingManual takes nothing returns nothing
    set manualDocking = true
endfunction

// This will interrupt docking when called on pre-dock
function InterruptDocking takes nothing returns nothing
    set interruptDocking = true
endfunction

// This will interrupt docking when called on pre-dock
function ResetUnitFlyHeight takes unit u returns nothing
    call SetUnitFlyHeight(u, GetUnitDefaultFlyHeight(u), 0.)
endfunction

struct Socket

    real x
    real y
    real z
    real facing
    unit plug
    unit station
    unit socketPointer
    boolean killSocketPointer
    boolean ignoreOrder
    integer slot
    trigger trig

    method destroy takes nothing returns nothing
        if this.plug != null then
            call DockingSystem.undock.evaluate(this.plug)
        endif

        set this.station = null
        set this.slot = 0

        if this.killSocketPointer then
            call UnitApplyTimedLife(this.socketPointer, 'BTLF', .01)
            set this.killSocketPointer = false
        endif

        if this.socketPointer != null then
            set DS_SocketId[GetUnitUserData(this.socketPointer)] = 0
            set this.socketPointer = null
        endif

        call this.deallocate()
    endmethod

    // Safety measure
    static if LIBRARY_WorldBounds then
        method secureBounds takes nothing returns nothing
            if this.x > WorldBounds.maxX then
                set this.x = WorldBounds.maxX
            elseif this.x < WorldBounds.minX then
                set this.x = WorldBounds.minX
            endif
            if this.y > WorldBounds.maxY then
                set this.y = WorldBounds.maxY
            elseif this.y < WorldBounds.minY then
                set this.y = WorldBounds.minY
            endif
        endmethod
    endif

endstruct


// Fires one of the four custom events of DockingSystem. These are registered with RegisterDockEvent above.
private function FireEvent takes unit plug, unit station, integer ev returns nothing
    local integer playerId = GetPlayerId(GetOwningPlayer(plug))
    local unit prevPlug = eventPlug
    local unit prevStation = eventStation

    set eventPlug = plug
    set eventStation = station

    call TriggerEvaluate(GetNativeEventTrigger(ev))
    if IsNativeEventRegistered(playerId, ev) then
        call TriggerEvaluate(GetIndexNativeEventTrigger(playerId, ev))
    endif

    set eventPlug = prevPlug
    set eventStation = prevStation
    set prevPlug = null
    set prevStation = null
endfunction


struct DockingSystem

    readonly Table tableInstance
    readonly integer maxSockets

    static if LIBRARY_ListT then
        readonly IntegerList busySockets
        readonly IntegerList freeSockets
    endif

    // stuns the unit after 0 seconds. Needed to prevent docked units from keeping on walking
    // once they get in range of a station. Also used to stop plugs from walking into a building
    // when they right-click on their current station.
    private static method zeroTimerStun takes nothing returns nothing
        local timer t = GetExpiredTimer()
        local Socket s = GetTimerData(t)

        set s.ignoreOrder = true
        call IssueImmediateOrderById(s.plug, 851973)//order stunned
        set s.ignoreOrder = false
        call ReleaseTimer(t)

        set t = null
    endmethod


    // core undocking method.
    static method undock takes unit plug returns nothing

        local integer id_P = GetUnitUserData(plug)
        local Socket s = DS_SocketId[id_P]
        local integer id_S

        // if s is 0 that means the unit is not docked and thus nothing happens.
        if s != 0 then
            set id_S = GetUnitUserData(s.station)
            set DS_PlugCount[id_S] = DS_PlugCount[id_S] - 1
            call SetUnitPathing(plug, true)
            set s.plug = null
            call DestroyTrigger(s.trig)
            set s.trig = null

            static if LIBRARY_ListT then
                call DS_Instance[id_S].busySockets.removeElem(s)
                call DS_Instance[id_S].freeSockets.push(s)
            endif

            call FireEvent(plug, s.station, EVENT_ON_UNDOCK)
            set DS_SocketId[id_P] = 0
        endif

    endmethod


    // this function cycles through all of a station's sockets and, if occupied, undocks them.
    static method undockAll takes unit station returns nothing

        local integer id_S = GetUnitUserData(station)
        local thistype this = DS_Instance[id_S]
        local integer i
        local Socket s

        static if LIBRARY_ListT then
            local IntegerListItem node = this.busySockets.first
            local IntegerListItem nodeNext
        endif

        // if unit station is not an actual station or has no sockets, this does nothing.
        if this != 0 then

            static if LIBRARY_ListT then

                loop
                    exitwhen node == 0
                    set nodeNext = node.next
                    set s = node.data
                    call DockingSystem.undock(s.plug)
                    set node = nodeNext
                endloop

            else
                set Station.s = this.tableInstance
                set i = this.maxSockets // goes from top to bottom.
                loop
                    set s = Station.s.integer[i]
                    if s.plug != null then
                        call DockingSystem.undock(s.plug)
                    endif
                    set i = i - 1
                    exitwhen i <= 0
                endloop
            endif

        endif

    endmethod


    // this function handles the order events of docked unit (aka plugs). Right-clicking on the
    // unit the plug is currently docked at will do nothing - this is handled in dockPrep.
    private static method trackOrders takes nothing returns nothing
        local unit plug     = GetTriggerUnit()
        local unit station  = GetOrderTargetUnit()
        local Socket s = DS_SocketId[GetUnitUserData(plug)]

        if not s.ignoreOrder then
            if not (station == s.station and GetIssuedOrderId() == ORDER_SMART) then
                call DockingSystem.undock(plug)
            endif
        endif

        set plug = null
        set station = null
    endmethod


    // core dock method.
    static method dock takes unit plug, Socket s returns nothing

        local integer id_S = GetUnitUserData(s.station)

        call FireEvent(plug, s.station, EVENT_ON_PRE_DOCK)

        if not interruptDocking then

            call TimerStart(NewTimerEx(s), 0., false, function thistype.zeroTimerStun)

            call SetUnitPathing(plug, false)
            call SetUnitX(plug, s.x)
            call SetUnitY(plug, s.y)

            if GetUnitAbilityLevel(plug, 852155) > 0 then
                call UnitAddAbility(plug, 852155)
                call UnitRemoveAbility(plug, 852155)
            endif

            call SetUnitFlyHeight(plug, s.z, 0.)
            call SetUnitFacing(plug, s.facing)

            set s.plug = plug
            set DS_SocketId[GetUnitUserData(plug)] = s

            if not manualDocking then
                set s.trig = CreateTrigger()
                call TriggerRegisterUnitEvent(s.trig, plug, EVENT_UNIT_ISSUED_TARGET_ORDER)
                call TriggerRegisterUnitEvent(s.trig, plug, EVENT_UNIT_ISSUED_POINT_ORDER)
                call TriggerRegisterUnitEvent(s.trig, plug, EVENT_UNIT_ISSUED_ORDER)
                call TriggerAddCondition(s.trig, function thistype.trackOrders)
            else
                set manualDocking = false
            endif

            set DS_PlugCount[id_S] = DS_PlugCount[id_S] + 1

            static if LIBRARY_ListT then
                call DS_Instance[id_S].freeSockets.removeElem(s)
                call DS_Instance[id_S].busySockets.push(s)
            endif

            call FireEvent(plug, s.station, EVENT_ON_DOCK)

        endif

        set interruptDocking = false

    endmethod


    // this function runs when a right-clicker is in range of a station.
    static method dockPrep takes nothing returns nothing
        local unit      station = GetTracker()
        local unit      plug = GetSmartUnit()
        local boolean   firstPass = false
        local boolean   exitLoop = false

        local thistype  this
        local Socket s = DS_SocketId[GetUnitUserData(plug)]

        // if s has no value, then the unit is not docked anywhere.
        if s == 0 then
            set s = GetClosestSocketWithState(station, plug, false)
            if s != 0 then
                call DockingSystem.dock(plug, s)
            endif

        // if s has a value, then the unit is already docked somewhere.
        else
            // if the station you right-clicked is the same station the unit is docked at, issue a stunned order and fires a EVENT_ON_REDOCK event.
            if s.station == station then
                call TimerStart(NewTimerEx(s), 0., false, function thistype.zeroTimerStun)
                call FireEvent(plug, s.station, EVENT_ON_REDOCK)
            else // undock the plug and dock it in the other station
                call DockingSystem.undock(plug)
                set s = GetClosestSocketWithState(station, plug, false)
                if s != 0 then
                    call DockingSystem.dock(plug, s)
                endif
            endif

        endif

        set station = null
        set plug = null
    endmethod


    // removes a socket from a station. If the socket is occupied, the unit is first undocked.
    static method removeSocket takes Socket s returns nothing

        local thistype this = DS_Instance[GetUnitUserData(s.station)]
        local integer i = s.slot

        if this != 0 then

            set Station.s = this.tableInstance

            static if LIBRARY_ListT then
                if s.plug == null then
                    call this.freeSockets.removeElem(s)
                else
                    call this.busySockets.removeElem(s)
                endif
            endif

            call s.destroy()
            call Station.s.remove(i)

            loop
                set Station.s.integer[i] = Station.s.integer[i + 1]
                set i = i + 1
                exitwhen i >= this.maxSockets
            endloop

            set this.maxSockets = this.maxSockets - 1

        endif

    endmethod


    // changes the x/y coordinates of a socket. If there a unit docked into it, the unit moves as well.
    static method moveSocket takes Socket s, real x, real y, real z, real facing returns nothing

        set s.x = x
        set s.y = y
        set s.z = z
        set s.facing = facing

        static if LIBRARY_WorldBounds then
            call s.secureBounds()
        endif

        if s.plug != null then
            //Move plug
            call SetUnitX(s.plug, x)
            call SetUnitY(s.plug, y)
            call SetUnitFacing(s.plug, facing)
            call SetUnitFlyHeight(s.plug, z, 0.)
        endif
    endmethod


    // socket pointers are proxies that allow you to dock a unit to a specific socket. See documentation for more info.
    static method addSocketPointer takes unit pointer, real range, boolean killPointer, Socket s returns nothing
        if pointer != null then
            set s.socketPointer = pointer
            set s.killSocketPointer = killPointer
            set DS_SocketId[GetUnitUserData(pointer)] = s
            call CreateSmartOrderTracker(pointer, range)
        endif
    endmethod


    // adds a socket to a station.
    static method addSocket takes unit station, real x, real y, real z, real facingAngle returns Socket

        local thistype this = DS_Instance[GetUnitUserData(station)]
        local Socket s

        // if the unit is not a Station this function does nothing.
        if this != 0 then
            set Station.s = this.tableInstance
            set this.maxSockets = this.maxSockets + 1

            set s = Socket.create()
            set s.x = x
            set s.y = y
            set s.z = z
            set s.facing = facingAngle
            set s.station = station
            set s.slot = this.maxSockets

            set Station.s.integer[this.maxSockets] = s

            static if LIBRARY_WorldBounds then
                call s.secureBounds()
            endif

            static if LIBRARY_ListT then
                call this.freeSockets.push(s)
            endif

        endif

        return s
    endmethod


    // this terminates the Station instance bound to a unit. Will undock all currectly-docked units.
    static method terminateStation takes unit station returns nothing

        local integer id_S = GetUnitUserData(station)
        local thistype this = DS_Instance[id_S]
        local integer i

        if this != 0 then
            set Station.s = this.tableInstance
            set i = this.maxSockets

            loop
                call removeSocket(Station.s.integer[i])
                set i = i - 1
                exitwhen i <= 0
            endloop

            set this.maxSockets = 0
            call CancelSmartOrderTracker(station)
            set DS_Instance[id_S] = 0
            call Station.s.destroy()

            static if LIBRARY_ListT then
                call this.busySockets.destroy()
                call this.freeSockets.destroy()
            endif

            call this.deallocate()
        endif

    endmethod


    // establishes a unit as a Station. Sockets are added separately. Only 1 Station instance
    // allowed per unit.
    static method createStation takes unit station, real socketTriggerDistance returns nothing

        local integer id_S = GetUnitUserData(station)
        local thistype this = DS_Instance[id_S]

        if this == 0 then
            set Station.s = Table.create()
            set this = allocate()
            set this.tableInstance = Station.s
            set this.maxSockets = 0
            call CreateSmartOrderTracker(station, socketTriggerDistance)
            set DS_Instance[id_S] = this
            set DS_PlugCount[id_S] = 0

            static if LIBRARY_ListT then
                set this.freeSockets = IntegerList.create()
                set this.busySockets = IntegerList.create()
            endif

        endif

    endmethod

endstruct

// this function sets up all events related to DockingSystem. It also sets up SmartTrack to fire
// DockingSystem.dockPrep whenever a unit gets in range of a tracker.
private module DockingSystemInit
    private static method onInit takes nothing returns nothing

        static if LIBRARY_WorldBounds then
            set MAX_DISTANCE =  (WorldBounds.maxX - WorldBounds.minX)*(WorldBounds.maxX - WorldBounds.minX) + /*
            */
                 (WorldBounds.maxY - WorldBounds.minY)*(WorldBounds.maxY - WorldBounds.minY)
        else
            set MAX_DISTANCE =  999999. * 999999.
        endif

        set EVENT_ON_PRE_DOCK  = CreateNativeEvent()
        set EVENT_ON_DOCK      = CreateNativeEvent()
        set EVENT_ON_UNDOCK    = CreateNativeEvent()
        set EVENT_ON_REDOCK    = CreateNativeEvent()

        call RegisterNativeEvent(EVENT_SMART_TRACK_IN_RANGE, function DockingSystem.dockPrep)
    endmethod
endmodule

private struct init
    implement DockingSystemInit
endstruct

endlibrary



Demo
Code (vJASS):

scope onDockEvent initializer init

    globals
        private effect array wispTail
        private constant string WISP_TAIL_FX = "Abilities\\Weapons\\IllidanMissile\\IllidanMissile.mdl"
    endglobals

    /*
        GetPlug() == Unit that is docking into the station
        GetStation() == The station with the docking ports

        I recommend storing those in a local variable if they will be called more than once.
        Do not forget to null the locals afterward to prevents leaks.

        Examples can be seen down below with the functions Actions_onDock, Actions_onUndock and
        Actions_onRedock.
    */


    private function onTrackStart takes nothing returns boolean

        /*
            The following are examples of how to filter out units with SmartTrack events.
        */


        local unit smarty = GetSmartUnit()
        local unit tracker = GetTracker()
        local integer smartyTypeId = GetUnitTypeId(smarty)
        local integer trackerTypeId = GetUnitTypeId(tracker)

        //Tauren Totem - Witch Doctors only
        if trackerTypeId == 'otto' then
            if smartyTypeId != 'odoc' then
                call SmartTrack.stop(smarty, true)
                call BJDebugMsg("    Witch Doctors only")
            endif
        endif

        //Chimera Roost - Archers only
        if trackerTypeId == 'edos' then
            if smartyTypeId != 'earc' then
                call SmartTrack.stop(smarty, false)
                call BJDebugMsg("    Archers only")
            endif
        endif

        //Spirit Tower - Wisps only
        if trackerTypeId == 'uzg1' then
            if smartyTypeId != 'ewsp' then
                call SmartTrack.stop(smarty, false)
                call BJDebugMsg("    Wisps only")
            endif
        endif

        set smarty = null
        set tracker = null

        return false
    endfunction


    private function Actions_onPreDock takes nothing returns boolean

        /*/*

            You can call /* InterruptDocking() */
in this function to prevent docking from
            happening.

            You can also call /* SetDockingManual() */ to prevent automatic undocking triggers from
            being created. For example, any orders that is NOT a right-click on the currently docked
            station will undock the plug. With SetDockingManual() you will have to undock the unit
            by youself. This can be useful if you wish to have docked units function as turrets, for
            example. Give them an ability upon docking that will undock them when used.

        */*/

        //Archer
        if GetUnitTypeId(GetPlug()) == 'earc' then
            call SetDockingManual()
        endif

        return false
    endfunction


    private function Actions_onDock takes nothing returns boolean

        local unit plug = GetPlug()
        local unit station = GetStation()
        local integer plugTypeId = GetUnitTypeId(plug)
        local integer stationTypeId = GetUnitTypeId(station)
        local integer plugId

        //Witch Doctor
        if plugTypeId == 'odoc' then
            call SetUnitAnimationWithRarity(plug, "stand victory", RARITY_FREQUENT)

        //Archer
        elseif plugTypeId == 'earc' then
            call SetUnitPropWindow(plug, 0.)
            call UnitAddAbility(plug, 'A000')

        //Wisp
        elseif plugTypeId == 'ewsp' then
            set plugId = GetUnitUserData(plug)
            if wispTail[plugId] == null then
                set wispTail[plugId] = AddSpecialEffectTarget(WISP_TAIL_FX, plug, "chest")
            endif

        endif


        //Chimera Roost
        if stationTypeId == 'edos' then
            if GetNumberOfOccupiedSockets(station) == 1 then
                call UnitAddAbility(station, 'A001')
            endif
        endif

        set plug = null
        set station = null

        return false
    endfunction


    private function Actions_onUndock takes nothing returns boolean

        /*/
*

            You can call /* ResetUnitFlyHeight(plug) */ in this function to reset your undocking
            unit's flying height to its default value.

        */*/

        local unit plug = GetPlug()
        local unit station = GetStation()
        local integer plugTypeId = GetUnitTypeId(plug)
        local integer stationTypeId = GetUnitTypeId(station)
        local integer plugId

        //Witch Doctor
        if plugTypeId == '
odoc' then
            if not UnitAlive(plug) then
                call SetUnitAnimation(plug, "death")
            else
                call SetUnitAnimation(plug, "stand")
            endif

        //Archer
        elseif plugTypeId == '
earc' then
            call SetUnitPropWindow(plug, GetUnitDefaultPropWindow(plug))
            call UnitRemoveAbility(plug, '
A000')
            call SetUnitPosition(plug, GetUnitX(station) + Cos(270. * bj_DEGTORAD) * 150., /*
            */ GetUnitY(station) + Sin(270. * bj_DEGTORAD) * 150.)
            call ResetUnitFlyHeight(plug)

        //Wisp
        elseif plugTypeId == '
ewsp' then
            set plugId = GetUnitUserData(plug)
            if wispTail[plugId] != null then
                call DestroyEffect(wispTail[plugId])
                set wispTail[plugId] = null
            endif

        endif

        //Chimera Roost
        if stationTypeId == '
edos' then
            if GetNumberOfOccupiedSockets(station) == 0 then
                call UnitRemoveAbility(station, '
A001')
            endif
        endif

        set plug = null
        set station = null

        return false
    endfunction


    private function Actions_onRedock takes nothing returns boolean

        local unit plug = GetPlug()
        local unit station = GetStation()
        local integer plugTypeId = GetUnitTypeId(plug)

        //Witch Doctor
        if plugTypeId == '
odoc' then
            call SetUnitAnimation(plug, "stand")
            call SetUnitAnimationWithRarity(plug, "stand victory", RARITY_FREQUENT)

        //Wisp
        elseif plugTypeId == '
ewsp' then
            call BJDebugMsg("This wisp is already docked at this Spirit Tower")

        endif

        set plug = null
        set station = null

        return false
    endfunction


    private function init takes nothing returns nothing
        call RegisterNativeEvent(EVENT_ON_PRE_DOCK, function Actions_onPreDock)
        call RegisterNativeEvent(EVENT_ON_DOCK, function Actions_onDock)
        call RegisterNativeEvent(EVENT_ON_UNDOCK, function Actions_onUndock)
        call RegisterNativeEvent(EVENT_ON_REDOCK, function Actions_onRedock)
        //Filter - use SmartTrack
        call RegisterNativeEvent(EVENT_SMART_TRACK_STARTED, function onTrackStart)
    endfunction

endscope


Version History
- v1.05.3 Added WorldBounds and ListT as optional requirements to for safety checks and slight performance boost respectively. The socket struct is now names Socket, as it should have always been (instead of P for plug - I had been confusing my own terminologies >_>). Finally fixed a potential bug and made the coding style more closely follow camelCase.
- v1.05.2 Added backward compatibility with slightly older versions of DockingSystem and fixed some bugs.
- v1.05.1 Added GetSocketFromPlug to return the socket in which a unit is plugged in. Also split GetNumberOfSocketsWithState into GetNumberOfOccupiedSockets and GetNumberOfEmptySockets and optimised the code.
- v1.05 Fixed a bug with interruptDocking() not working. DockingSystem will now pick the closest Socket to dock into. Also added the function ResetUnitFlyHeight(your unit) to reset an undocking plug's height on Undocking.
- v1.04 updated to work with SmartTrack v1.05, which now uses RegisterPlayerUnitEvent and RegisterNativeEvent. Updated event names for standardisation.
- v1.03 Must now use wrapper functions GetPlug() and GetStation() to obtain the plug unit and station unit respectively during events. Demo code has been updated to demonstate their use. Also fixed an improperly classed member (tableInstance is now a Table rather than integer) and updated SmartTrack to 1.03.
- v1.02 cleaned up the code and added comments to explain most functions. Added a new event for redocking and updated the demo to explain how it can be used. Also updated SmartTrack to v1.02.1
- v1.01 added some additional API funcitonality
- v1.00 initial release
Contents

DockingSystem v1.05.3 (Map)

Reviews
MyPad
Nitpicks: In struct S, making it private would make more sense, since it isn't referred outside of the system. Notes: It is preferable to indicate private members. Same applies for globals. Struct naming would be more optimal. For example, P could...
  1. Spellbound

    Spellbound

    Joined:
    Jan 9, 2005
    Messages:
    1,916
    Resources:
    15
    Skins:
    5
    Spells:
    9
    JASS:
    1
    Resources:
    15
    Reserved

  2. Dracaratos

    Dracaratos

    Joined:
    Mar 20, 2014
    Messages:
    66
    Resources:
    0
    Resources:
    0
    Works great, using in my current map, Azeroth Defense, also might use in Island Defense v4.0.0.108 Beta

  3. Spellbound

    Spellbound

    Joined:
    Jan 9, 2005
    Messages:
    1,916
    Resources:
    15
    Skins:
    5
    Spells:
    9
    JASS:
    1
    Resources:
    15
    Great to hear! Do you think DockingSystem should have an internal filtering system to determine what units/unit types/players can use them, or are you comfortable with setting those parameters on your own? I'm currently looking into this idea.

  4. Dracaratos

    Dracaratos

    Joined:
    Mar 20, 2014
    Messages:
    66
    Resources:
    0
    Resources:
    0
    @Spellbound I'm currently filtering them on my own, and that's really how it should be. I think a trigger included to show how to filter would be nice for the greener people, but I'm comfortable setting them on my own.

    I would argue the folders and triggers could use some more explanation (such as if I wanted to implement this for my own totem, what's the process?) for someone that doesn't know how to read all this.

    Side-Note: Copying things from one map to another is easier with one folder ;)

    I appreciate the system, it's great for me, personally I'm using it as lives in a Defend-Azeroth (Similar to Custom Castle Defense) type game, and it will stay and probably be used for other things

  5. Spellbound

    Spellbound

    Joined:
    Jan 9, 2005
    Messages:
    1,916
    Resources:
    15
    Skins:
    5
    Spells:
    9
    JASS:
    1
    Resources:
    15
    Hmm, personally I would be okay with just giving some examples and not having to make a dynamic filter system (it's work, lol). I made a little mock-up in SmartTracking. I'm need some feedback on it.

    As for the folders, they're mostly there for organisation. I'll see about adding some more descriptions and explanations to the non-system triggers :)

  6. Dracaratos

    Dracaratos

    Joined:
    Mar 20, 2014
    Messages:
    66
    Resources:
    0
    Resources:
    0
    It's a great system, I really appreciate you making it, 5/5 from me

  7. Chaosy

    Chaosy

    Joined:
    Jun 9, 2011
    Messages:
    10,573
    Resources:
    18
    Maps:
    1
    Spells:
    11
    Tutorials:
    6
    Resources:
    18
    Cool.

    Misleading name though I suppose?

  8. Spellbound

    Spellbound

    Joined:
    Jan 9, 2005
    Messages:
    1,916
    Resources:
    15
    Skins:
    5
    Spells:
    9
    JASS:
    1
    Resources:
    15
    Not really? You can technically use it in a sci-fi map with starports and spaceships that dock into it. Not sure what else I should call it.

  9. Spellbound

    Spellbound

    Joined:
    Jan 9, 2005
    Messages:
    1,916
    Resources:
    15
    Skins:
    5
    Spells:
    9
    JASS:
    1
    Resources:
    15
    Updated the demo map (had to update SmartTrack) and expanded the demo to show how filtering can be done. DockingSystem itself remains unchanged, thus why it's still v1.00.

  10. Spellbound

    Spellbound

    Joined:
    Jan 9, 2005
    Messages:
    1,916
    Resources:
    15
    Skins:
    5
    Spells:
    9
    JASS:
    1
    Resources:
    15
    Updated to v1.01. Added some more function calls that you can use:
    Code (vJASS):
        call GetRandomSocket( takes unit station )
            returns the instance of a random socket.

        call GetRandomSocketWithState( takes unit station, boolean is_socket_occupied )
            returns the instance of a socket. If the boolean is true, returns an occupied socket. If
            fakse, returns a vacant one.

        call GetNumberOfSockets( takes unit station )
            returns the total number of sockets the station has.

        call GetNumberOfSocketsWithState( takes unit station, boolean is_socket_occupied )
            returns the total number of sockets the station has. If the boolean is true, only counts
            occupied sockets. If false, only counts vacant ones.

        call GetSocketPlug( takes P socket_instance )
            returns the unit currently docked in that socket. If the socket is empty, returns null.

  11. Dracaratos

    Dracaratos

    Joined:
    Mar 20, 2014
    Messages:
    66
    Resources:
    0
    Resources:
    0
    What's the max number of units that you should dock?

  12. Spellbound

    Spellbound

    Joined:
    Jan 9, 2005
    Messages:
    1,916
    Resources:
    15
    Skins:
    5
    Spells:
    9
    JASS:
    1
    Resources:
    15
    There is no limit. You can add as many Sockets as you want to a Station.

  13. Spellbound

    Spellbound

    Joined:
    Jan 9, 2005
    Messages:
    1,916
    Resources:
    15
    Skins:
    5
    Spells:
    9
    JASS:
    1
    Resources:
    15
    Note to reviewer: I will be updating this system today. Please hold off any moderation until I do.

    EDIT: Updated to v1.02:

    Last edited: Jan 28, 2018
  14. btdonald

    btdonald

    Joined:
    Dec 3, 2011
    Messages:
    349
    Resources:
    8
    Maps:
    1
    Spells:
    7
    Resources:
    8
    I'm very happy that you're still doing shit <3 AWESOME

  15. Spellbound

    Spellbound

    Joined:
    Jan 9, 2005
    Messages:
    1,916
    Resources:
    15
    Skins:
    5
    Spells:
    9
    JASS:
    1
    Resources:
    15
    Heh, thanks. I learned some code since :p

  16. SnowYell

    SnowYell

    Joined:
    Jun 13, 2010
    Messages:
    308
    Resources:
    0
    Resources:
    0
    This is quite brilliant actually! I imagine this may inspire a lot of map creators trying to do some unique faction features. Well done.

  17. MyPad

    MyPad

    Spell Reviewer

    Joined:
    May 9, 2014
    Messages:
    1,258
    Resources:
    6
    Models:
    1
    Icons:
    1
    Spells:
    3
    JASS:
    1
    Resources:
    6

    Nitpicks:


    • In struct S, making it private would make more sense, since it isn't referred outside of the system.

    Notes:


    • It is preferable to indicate private members. Same applies for globals.
    • Struct naming would be more optimal. For example, P could be renamed Plug, and S could be Socket.

    Status:



    Awaiting Update

    Last edited: Jun 10, 2018
  18. Spellbound

    Spellbound

    Joined:
    Jan 9, 2005
    Messages:
    1,916
    Resources:
    15
    Skins:
    5
    Spells:
    9
    JASS:
    1
    Resources:
    15
    Updated per suggestions and requirements.
    Cheers!

  19. MyPad

    MyPad

    Spell Reviewer

    Joined:
    May 9, 2014
    Messages:
    1,258
    Resources:
    6
    Models:
    1
    Icons:
    1
    Spells:
    3
    JASS:
    1
    Resources:
    6
    I forgot to update the tag from Pending to Awaiting Update. Sorry for that :p
