Pull&Push 3D System v1.3

Pull (or Push) 3D System v1.3
by Lender


This system makes easier the making of spells that requires unit moving
like: -knockbacks
-barriers
-charges etc...

Can be integrated easily in spells.
This will do the hard work for you.

Unit hitting, Destructible hitting, Toss Effect, Bounce Effect, many Events,
many Customizable Variables, How to Import/How to Use (Tutorial/Documentation)

Hope the system will helps for a lot of people !

1.3 : Remade the Toss calculations that makes the leap much (MUCH) smoother (toss effect). Added .isJump for: Pulled unit will reach it's destination (determined by the user) with one single jump.(note that it's still a tossing so it has onLanding event as well)

1.2 : Added a Toss effect with onLanding event , Bouncing effect from walls, only when "pushing" with onBounce event, slightly improved the pretty noob pathing checks thanks to Bribe:). Added "How to Import" and "How to Use" tutorial documents and two more demo spells.

1.1 : Handling the instances in a linked list instead of a struct array. Got rid of the API problem . Removed some useless parts . More comments and better categorization . Replaced the interface with implemented stub methods.


JASS:
library PullPushSystem

  //------------------------------------------------------//
 //          Default values(change if you want)          //
//------------------------------------------------------//
globals
    constant    real            PULL_PERIOD                 = 0.03125   // time period - dose the units positioning 32 times in a sec
    constant    real            PULL_SPEED_DEFAULT          = 320.      // pulled units movespeed
    constant    real            PULL_HIT_RANGE              = 100.      // default range of hitting
    constant    real            PULL_SLOWSTART              = 1.        // default time needs to pass before it starts changing the units movespeed
    constant    real            PULL_SLOWING                = 0.625     // 0.625 / 0,03125 = 20 movespeed decrease per second->
                                                                        // -> for x movespeed increase you need to set this to x*0.03125->
                                                                        // ->setting this to a negative amount will occure ms increasing
    constant    real            PULL_TOSS_STARTVELOCITY     = 2000.     // default value of how fast the pulled unit will be tossed up
    constant    integer         PULL_TOSSNUMBER             = 1         // default value of how many times the pulled unit will be tossed after eachother
endglobals

//----------------DO NOT CHANGE THESE METHODS RIGHT HERE BUT IN YOUR OWN SCRIPTS------------
//----------------------------LOOK FOR THE DEMO SPELLS HOW TO DO THAT-----------------------
module Events
    //this will fire only once when the unit is prepared to be pulled
    //( SET HERE THE VALUES SEEN UNDER )-----------------------------------------------------
    stub method onPullStart takes nothing returns nothing                                   //
    endmethod                                                                               //
                                                                                            //
    //this event will be called in every time period                                        //
    //( YOU ARE FREE TO CHANGE VALUES HERE WHILE THE UNIT MOVES )                           //
    stub method onAction takes unit target returns nothing                                  //
    endmethod                                                                               //
                                                                                            //
    //this event will be called when the moving unit touches a destructable                 //
    // isDestHit must be enabled (set true) to use this                                     //
    stub method onDestHit takes destructable d returns nothing                              //
    endmethod                                                                               //
                                                                                            //
    //this event will be called when the moving unit touches a unit                         //
    // isUnitHit must be enabled (set true) to use this                                     //
    stub method onUnitHit takes unit u returns nothing                                      //
    endmethod                                                                               //
                                                                                            //
    //if your moving unit has a UNIT as Destination                                         //
    //this event will be called when the Target unit touches the Unit                       //
    stub method onAtDestUnit takes unit DestUnit ,unit Target returns nothing               //
    endmethod                                                                               //
                                                                                            //
    //this event will be called when the Targets movespeed becomes <=0 (stops:P)            //
    stub method onStop takes unit Target returns nothing                                    //
    endmethod                                                                               //
                                                                                            //
    //if your moving unit has a POINT(x,y coordinates not location) as Destination          //
    //this event will be called when the Target unit reaches the point                      //
    stub method onAtDestPoint takes unit Target returns nothing                             //
    endmethod                                                                               //
                                                                                            //
    //this event will be called if the pulled unit was tossed when it reaches the ground    //
    stub method onLanding takes unit Target returns nothing                                 //
    endmethod                                                                               //
                                                                                            //
    //this event will be called when the pulled unit bounces off something                  //
    //.isBouncing have to be ture                                                           //
    stub method onBounce takes unit Target returns nothing                                  //
    endmethod                                                                               //
                                                                                            //
endmodule                                                 //------------------------------------------------------//
                                                         //  values that should be set when "onPullStart" fires  //
//------------------------------------------------------//------------------------------------------------------//
                                                       // these are just the defaults,set them in your trigger //
                                                      //           With onPullStart adn/or onAction           //

struct Pulling
implement Events
//-----Generic stuff-------------------------------------------------
    public              real                pullSpeed                   = PULL_SPEED_DEFAULT    // pulled units movespeed
    public              boolean             pausing                     = true                  // set this false to pull units without pausing theme
    public              boolean             isPulled                    = true                  // set it true to pull, false to push the unit
    public              boolean             disablePathing              = true                  // set false to NOT disable pathing for unit

//-----Hitting and pathing-------------------------------------------
    public              boolean             isCheckPathing              = true                  // set this false to don't check pathing ( walkability )
    public              boolean             hitDests                    = true                  // set this false to don't hit destructables
    public              boolean             hitUnits                    = true                  // set this false to don't hit units
    public              real                hitRange                    = PULL_HIT_RANGE        // range between units counts as a hit

//-----Slowing (Speeding)--------------------------------------------
    public              boolean             isSlowing                   = false                 // set true to turn slowing option on
    public              real                slowStart                   = PULL_SLOWSTART        // needed time to pass before start the slowing
    public              real                slowAmount                  = PULL_SLOWING          // for x movespeed decrease you need to set this to x*0.03125
                                                                                                // negative value will couse movespeed increase
//-----Area of Effect------------------------------------------------
    public              boolean             hasAOE                      = false                 // set true to get your spell an area of effect
    public              real                aoeRadius                   = 200.                  // the radius of the spells AoE

//-----Units---------------------------------------------------------
    readonly            unit                destUnit                    = null                  // if the destination is a unit this variable stores it
    readonly            unit                victim                      = null                  // target unit , moved unit

//-----Offset--------------------------------------------------------
    readonly            real                tossOrdinalNumber           = 0.                        // contains the ordinal number of the actual toss
    public              real                tossStartVelocity           = PULL_TOSS_STARTVELOCITY   // base value of how fast the pulled unit will be tossed at the first time when the pull starts
    public              boolean             isTossed                    = false                     // set this true to enable tossing
    public              boolean             isJump                      = false                     // if isJump is true system calculates variables for a big leap insted of the normal toss effect
    public              integer             tossNumber                  = PULL_TOSSNUMBER           // sets the amount how much times the pulled unit will be tossed after eachother

//-----Bouncing------------------------------------------------------
    public              boolean             isBouncing                  = false                     // turn this true if you want your target bouncing off cliffs or map boarder

//-----------------------------------------------------------------------------------------------------------------
//-----------------------------------------------------------------------------------------------------------------
  //------------------------------------------------------//
 //   Values used by the system . SHOULDN'T BE CHANGED   //
//------------------------------------------------------//
    private static      boolean             refreshedPathings           = false     //prevents enabling pathing for pulled units that have pathing disabled if more then one pullorpush-spells were casted at the same time
    private             boolean             isPaused                    = false     //turns to true when the unit is paused
    private             real                pulledX                     = 0.        //pulled units x coord
    private             real                pulledY                     = 0.        //pulled units y coord
    private             real                pulledZ                     = 0.        //pulled units z coord
    private             real                pulltoX                     = 0.        //destinations x coord
    private             real                pulltoY                     = 0.        //destinations y coord
    private             real                calcX                       = 0.        //periodic pulling vectors x coord
    private             real                calcY                       = 0.        //prriodic pulling vectors y coord
    private             real                calcZ                       = 0.        //prriodic pulling vectors z coord
    private             integer             slowTick                    = 0         //period counter for slowstart
    private             boolean             hasUnitDest                 = false     //turns true if the targeted destination is a unit
    private static      timer               t                           = null      //period timer
    private static      integer             count                       = 0         //instance counter
    private             integer             tossCount                   = 0         //Tosses made already
    private             real                tossVelocity                = 0         //Tosses made already
    private             real                gravity                     = 150
    private             boolean             active                      = false     //turns true when the pulling begins
    private static      thistype            curPull                     = 0         //equals to the current running instance
    private             boolean             isPulReg                    = false     //turns true when instance registered to the struct array
    private static      rect                rec                         = null      //hitting detection rect
    private             boolean             notPathed                   = false     //turns true when units pathing turned off
    private             real                pullAngle                   = 0.        //stores the pulling Angle in radians
    private             integer             dummySpellLvl               = 0
    private             thistype            next
    private             thistype            prev
    private static      thistype            first
    private static      thistype            last
    private static      thistype            thiss
    private static      unit                dummy
//-------------------------------------------------------------------------------------------------------------------------------

    ///////////////////////////////////////////////////////////////////////////////////////
   //                                                                                   //
  //            SYSTEM METHODS. DON'T EDIT ANYTHING UNDER WITHOUT PERMISSION           //
 //                                                                                   //
///////////////////////////////////////////////////////////////////////////////////////

//--------------------------------------------------------------------
//---------PULLED AND (IF NEEDED)DESTINATION UNIT SAVING--------------
//-------------------CAN AND *SHOULD* BE USED FREELY------------------
    public method SetDestUnit takes unit u returns nothing
        set .destUnit = u
        set .hasUnitDest = true
    endmethod

    public method SetPullUnit takes unit u returns nothing
        if IsUnitPaused(.victim) then
            call PauseUnit(.victim,false)
            call PauseUnit(u,true)
        endif
        if .disablePathing then
            call SetUnitPathing(.victim,true)
            call SetUnitPathing(u,false)
        endif
        set .victim = u
        set .pulledX = GetUnitX(u)
        set .pulledY = GetUnitY(u)
        //! runtextmacro SetCollisionMacro()
    endmethod

    //---- STOP METHOD ----------------------------------------
    public method SuddenStop takes nothing returns nothing
        set .active = false
        if .isTossed then
                set .isTossed = false
                call SetUnitFlyHeight(.victim,0.,1000)
            endif
        if .notPathed then
            call SetUnitPathing(.victim,true)
            set thistype.refreshedPathings = false
        endif
        if .isPaused then
            call PauseUnit(.victim,false)
        endif
        if GetWidgetLife(.victim) > 0.405 then
            call .onStop(.victim)
        endif
    endmethod

//--------------------------------------------------------------------
//---------calculating periodic x and y movement----------------------
//--------------------------------------------------------------------
    private method calcXY takes nothing returns nothing
        local       real        velocity        = .pullSpeed * PULL_PERIOD
        set .calcX = velocity * Cos(.pullAngle)
        set .calcY = velocity * Sin(.pullAngle)
    endmethod

//--------------------------------------------------------------------
//---------TOSS CALCULATIONS------------------------------------------
//--------------------------------------------------------------------

    private method calculateZ takes nothing returns nothing
        if .tossCount < .tossNumber then
            set .tossVelocity = .tossVelocity - .gravity
            if GetWidgetLife(.victim) > 0.405 then
                set .calcZ = .calcZ + (.tossVelocity * PULL_PERIOD)
            else
                set .calcZ = 0.
                call SetUnitFlyHeight(.victim,0.,100000)
            endif
        else
            set .calcZ = 0.
            set .isTossed = false
        endif
        if .calcZ < 0 then
            set .calcZ = 0.
        endif
    endmethod

    private method setUpJumpProperties takes nothing returns nothing
        local real s = SquareRoot((.pulltoX-.pulledX)*(.pulltoX-.pulledX)+(.pulltoY-.pulledY)*(.pulltoY-.pulledY))
        local real t
        if s <= 800 then
            set t = 1. + ((s - 800.)/10000)
        else
            set t = 1. + ((s - 800.)/5000)
        endif
        set .isPulled = true
        set .hitRange = 0.01
        set .isSlowing = false
        set .isTossed = true
        set .tossNumber = 1
        set .isBouncing = false
        set .isCheckPathing = false
        set .pullSpeed = s/t
        set .tossStartVelocity = ((t/PULL_PERIOD)*.gravity)/2
    endmethod

//--------------------------------------------------------------------
//---------HIT DETECTIONING , EVENT RELEASING-------------------------
//--------------------------------------------------------------------

    //-----dest hit-----
    private static method HitDests takes nothing returns boolean
        local thistype this = thistype.curPull
        if not .isPaused then
            call PauseUnit(.victim,true)
        endif
        if .onDestHit.exists then
            call .onDestHit(GetFilterDestructable())
        endif
        call PauseUnit(.victim,false)
        return false
    endmethod

    //-----unit hit-----
    //! textmacro UnitHitMacro takes UNIT, X, Y, RADIUS
    call GroupEnumUnitsInRange(bj_lastCreatedGroup, .$X$, .$Y$, .$RADIUS$ + 172, null)
    loop
        set $UNIT$ = FirstOfGroup(bj_lastCreatedGroup)
        exitwhen $UNIT$ == null
        call GroupRemoveUnit(bj_lastCreatedGroup, $UNIT$)
        if $UNIT$ != .victim then
            if IsUnitInRangeXY($UNIT$, .$X$, .$Y$, .$RADIUS$) then
    //! endtextmacro

    //! textmacro UnitHitMacroEnd
            endif
        endif
    endloop
    //! endtextmacro

//-------------------------------------------------------------------
//---------Pathing Location Calculation (is it pathable ahead?)------
//-------------------------------------------------------------------

    private method calcModAngleXY takes nothing returns boolean
        local       real        modX        = .pulledX + (.dummySpellLvl*16+1) * Cos(.pullAngle)
        local       real        modY        = .pulledY + (.dummySpellLvl*16+1) * Sin(.pullAngle)
        return not IssuePointOrderById(.dummy,0xD0100,modX,modY)
    endmethod

//--------------------------------------------------------------------
//---------UNIT MOVEMENT , POSITIONING--------------------------------
//--------------------------------------------------------------------

    private method positioning takes nothing returns nothing
        local unit u = null
        local real lx
        local real ly
        local real atan
        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----The units death will break the instance----//
        if GetUnitState(.victim,UNIT_STATE_LIFE) > 0.405 then

        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----Setting the units pathing-----------------//
            if .disablePathing then
                if not thistype.refreshedPathings then
                    set .notPathed = thistype.refreshedPathings
                    set thistype.refreshedPathings = true
                endif
                if not .notPathed then
                    set .notPathed = true
                    call SetUnitPathing(.victim,false)
                endif
            endif

        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----Pausing the unit for the pulls duration----//
            if .pausing then
                set .isPaused = IsUnitPaused(.victim)
                if not (.isPaused) then
                    call PauseUnit(.victim,true)
                    set .isPaused = true
                endif
            endif

        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----Refreshing pull Angle----------------------//

                    //--refreshing the units location--
                    set .pulledX = GetUnitX(.victim)
                    set .pulledY = GetUnitY(.victim)

            if .hasUnitDest then
                if .destUnit != null then
                    set .pulltoX = GetUnitX(.destUnit)
                    set .pulltoY = GetUnitY(.destUnit)
                    if .isPulled then
                        set .pullAngle = Atan2(.pulltoY-.pulledY,.pulltoX-.pulledX)
                    else
                        set .pullAngle = Atan2(.pulledY-.pulltoY,.pulledX-.pulltoX)
                    endif
                endif
            endif

        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----Periodic Rising (Z value)------------------//
            if .isTossed then
                call .calculateZ()
                call SetUnitFlyHeight(.victim,.calcZ,10000)
                if .calcZ == 0 then
                    call .onLanding(.victim)
                    if .isJump then
                        call SuddenStop()
                    endif
                    set .tossCount = .tossCount+1
                    set .tossOrdinalNumber = .tossCount
                    set .tossStartVelocity = .tossStartVelocity*2/3
                    set .tossVelocity = .tossStartVelocity
                endif
            endif

        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----Pathing check------------------------------//
            if .isCheckPathing then

            //----Save Collision modifiers for victim----
            //! textmacro SetCollisionMacro
                if not IsUnitInRangeXY(.victim, .pulledX + 17, .pulledY, 0.) then
                    set .dummySpellLvl = 1
                elseif not IsUnitInRangeXY(.victim, .pulledX + 33, .pulledY, 0.) then
                    set .dummySpellLvl = 2
                elseif not IsUnitInRangeXY(.victim, .pulledX + 49, .pulledY, 0.) then
                    set .dummySpellLvl = 3
                else
                    set .dummySpellLvl = 4
                endif
            //! endtextmacro
                call PauseUnit(.dummy,false)
                call SetUnitAbilityLevel(.dummy,'ppds',.dummySpellLvl)
                if .calcModAngleXY() then
                    if not .isPulled and not .hasUnitDest then
                        set .pullAngle = (360.-(.pullAngle*bj_RADTODEG)) * bj_DEGTORAD
                        if .calcModAngleXY() then
                            set .pullAngle = (ModuloReal(180.+(.pullAngle*bj_RADTODEG),360.)) * bj_DEGTORAD
                            if .calcModAngleXY() then
                                set .pullAngle = (360.-(.pullAngle*bj_RADTODEG)) * bj_DEGTORAD
                                if .isBouncing then
                                    call .onBounce(.victim)
                                else
                                    call .SuddenStop()
                                endif
                            else
                                if .isBouncing then
                                    call .onBounce(.victim)
                                else
                                    call .SuddenStop()
                                endif
                            endif
                        else
                            if .isBouncing then
                                call .onBounce(.victim)
                            else
                                call .SuddenStop()
                            endif
                        endif
                    else
                        call .SuddenStop()
                    endif
                endif
                call PauseUnit(.dummy,true)
            endif

        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----X and Y vector calc for a period-----------//
            call .calcXY()

        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----Placing the unit to the next point---------//
            if .active then
                set .pulledX = .pulledX+.calcX
                set .pulledY = .pulledY+.calcY
                call SetUnitPosition(.victim,.pulledX,.pulledY)
            endif

        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----Hit detection for units and destructables--//
            if .hitDests then
                call SetRect(thistype.rec, .pulledX-.hitRange , .pulledY-.hitRange , .pulledX+.hitRange , .pulledY+.hitRange)
                call EnumDestructablesInRect(thistype.rec, Condition(function thistype.HitDests), null)
            endif


            if .hitUnits then
                //! runtextmacro UnitHitMacro("u","pulledX","pulledY","hitRange")
                            if .onUnitHit.exists then
                                call .onUnitHit(u)
                            endif
                //! runtextmacro UnitHitMacroEnd()
            endif
        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----Speed reduction/increase-------------------//
            if .isSlowing then
                if .slowStart <= .slowTick*PULL_PERIOD then
                    set .pullSpeed = .pullSpeed - .slowAmount
                endif
            endif

        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----Checks if the unit reached its destination-//
            if .isPulled then
                if .active then
                    if (.pulltoX-.pulledX)*(.pulltoX-.pulledX)+(.pulltoY-.pulledY)*(.pulltoY-.pulledY) <= .hitRange*.hitRange  then
                        set .active = false
                        if .notPathed then
                            call SetUnitPathing(.victim,true)
                            set thistype.refreshedPathings = false
                        endif
                        if .isPaused then
                            call PauseUnit(.victim,false)
                        endif
                        if .hasUnitDest then
                            call .onAtDestUnit(.destUnit,.victim)
                        else
                            call .onAtDestPoint(.victim)
                        endif
                    endif
                endif
            endif

        //ooooooooooooooooooooooooooooooooooooooooooooooo//
        //----Checks if a unit has 0 moving speed--------//
            if .active then
                if .pullSpeed <= 0. then
                    call .SuddenStop()
                endif
            endif

        //--------------counting--------------------------
            set .slowTick = .slowTick + 1
        else
        //--------------dead unit brakes the instance-----
            call .SuddenStop()
        endif
    endmethod



//--------------------------------------------------------------------
//STRUCT CREATION , REGISTRATION , INSTANCE HANDLING FOR MULTI STRUCTS
//--------------------------------------------------------------------
    //-------------EVENT RELEASING IN EVERY TIME PERIOD---------------
    private method action takes nothing returns nothing
        call .onAction(.victim)
        call .positioning()
    endmethod

    //----------------STRUCT LIST HANDLING---------------------------
    static method pull takes nothing returns nothing
            local thistype trash
            set thistype.thiss = thistype.first.next
            loop
                exitwhen thistype.thiss == thistype.last
                if thistype.thiss.active and thistype.thiss != 0 then
                    set thistype.curPull = thistype.thiss
                    call thistype.thiss.action()
                else
                    if thistype.thiss != 0 then
                        set thistype.thiss.next.prev = thistype.thiss.prev
                        set thistype.thiss.prev.next = thistype.thiss.next
                        set trash = thistype.thiss
                        set thistype.thiss = thistype.thiss.prev
                        call trash.destroy()
                    endif
                    set thistype.count = thistype.count -1
                endif
                set thistype.thiss = thistype.thiss.next
            endloop

            if thistype.count <= 0 then
                set thistype.count = 0
                call PauseTimer(thistype.t)
            endif
    endmethod

    //-------------------REGISTERING-----LINKING IN THE LIST--------------------
    public method start takes real x, real y, real x2, real y2 returns nothing
        local   thistype    lth     = thistype.last
        set     .pulledX            = x
        set     .pulledY            = y
        set     .pulltoX            = x2
        set     .pulltoY            = y2
        set thistype.refreshedPathings = false
        call .onPullStart()
        if .isPulled then
            set .pullAngle = Atan2(y2-y,x2-x)
        else
            set .pullAngle = Atan2(y-y2,x-x2)
        endif
        if .isJump then
            call setUpJumpProperties()
        endif
        if .isTossed then
            call UnitAddAbility(.victim,'Amrf')
            call UnitRemoveAbility(.victim,'Amrf')
            set .tossVelocity = .tossStartVelocity
        endif
        if not .isPulReg then
            set .active = true
            set .isPulReg = true
            //this goes here and there and that goes there and here...
            set .prev = lth.prev
            set .next = lth
            set .prev.next = this
            set lth.prev = this
            set thistype.count = thistype.count + 1
            if thistype.count == 1 then
                call TimerStart(thistype.t, PULL_PERIOD, true, function thistype.pull)
            endif
        endif
    endmethod

//----------------------------------------------------------------------------------------------------------
//-------------INITIALIZATIONS------------------------------------------------------------------------------
//----------------------------------------------------------------------------------------------------------
    private static method onInit takes nothing returns nothing
        set thistype.t          = CreateTimer()
        set thistype.rec        = Rect(0.,0.,0.,0.)
        set thistype.dummy      = CreateUnit(Player(PLAYER_NEUTRAL_PASSIVE),'psdu',0.,0.,0.)
        call PauseUnit(thistype.dummy,true)
        set thistype.first      = .create()
        set thistype.last       = .create()
        set thistype.first.next = thistype.last
        set thistype.last.prev  = thistype.first
    endmethod
endstruct

endlibrary

Keywords:
System, Pull, Push, Spell Maker, Unit Mover, Toss, Jump, Bounce, Knockback
Contents

Just another Warcraft III map (Map)

Reviews
6th Apr 2012 Bribe: Looks alright. There are a large number of issues using stub methods on such a large scale but ultimately it is up to the user to decide if it's too much.

Moderator

M

Moderator

6th Apr 2012
Bribe: Looks alright. There are a large number of issues using stub methods on such a large scale but ultimately it is up to the user to decide if it's too much.

Level 12
Joined
Oct 16, 2010
Messages
680
that is not possible since you have to create a struct for your script which extends the system struct

the only way to use it is like i did in the demos.

If you need some explanation, here i am
not so hard to understand anyway

EDIT: well actually there IS a way to do it in gui but nearly the same:D

  • DemoSpell
    • Events
    • Conditions
    • Actions
      • Custom script: endfunction
      • Custom script:
      • Custom script:
      • Custom script:
      • Custom script:
      • Custom script:
      • Custom script:
      • Custom script:
      • Custom script: struct demospell extends Pulling
      • Custom script:
      • Custom script:
      • Custom script: private static method spell takes nothing returns nothing
      • If (All Conditions are True) then do (Then Actions) else do (Else Actions)
        • If - Conditions
          • (Ability being cast) Equal to Pull
        • Then - Actions
          • Custom script: call setup(thistype.create())
        • Else - Actions
      • Custom script: endmethod
      • Custom script:
      • Custom script: private static method setup takes thistype this returns nothing
      • Custom script: local unit c = GetTriggerUnit()
      • Custom script: local unit t = GetSpellTargetUnit()
      • Custom script: local real cx = GetUnitX(c)
      • Custom script: local real cy = GetUnitY(c)
      • Custom script: local real tx = GetUnitX(t)
      • Custom script: local real ty = GetUnitY(t)
      • Custom script: call .SetPullUnit(t)
      • Custom script: call .SetDestUnit(c)
      • Custom script: call .start(tx, ty, cx, cy)
      • Custom script: endmethod
      • Custom script:
      • Custom script: method onAction takes unit Target returns nothing
      • Custom script:
      • -------- ----------------------------------------------------------------------- --------
      • -------- insert here (and in other events) what you want --------
      • -------- ----------------------------------------------------------------------- --------
      • Custom script:
      • Custom script: endmethod
      • Custom script:
      • Custom script: private static method onInit takes nothing returns nothing
      • Custom script: local trigger t = CreateTrigger()
      • Custom script: local integer i = 0
      • Custom script: loop
      • Custom script: exitwhen i == 12
      • Custom script: call TriggerRegisterPlayerUnitEvent(t,Player(i),EVENT_PLAYER_UNIT_SPELL_EFFECT,null)
      • Custom script: set i = i + 1
      • Custom script: endloop
      • Custom script: call TriggerAddAction(t, function thistype.spell)
      • Custom script: endmethod
      • Custom script:
      • Custom script:
      • Custom script: endstruct
      • Custom script:
      • Custom script:
      • Custom script:
      • Custom script:
      • Custom script:
      • Custom script:
      • Custom script:
      • Custom script: function blabla takes nothing returns nothing

Last edited:
Level 1
Joined
Nov 10, 2012
Messages
1
How can I modify the cooldown of the leap ability? I try to edit the ability cooldown from 0.0 to 3.0 but its still 0.0 in game no matter what. :(

Level 9
Joined
Dec 12, 2007
Messages
489
I think there's a resource rules that if the moderators are already approved the spell and if you want to update it, it must have at least 7 days or it will get rejected if you update the approved resource in greater than 7 days. Or better read this ^^: http://www.hiveworkshop.com/forums/faq/rulesandpolicies/#faq_resourcesubmissionrulesandguidelines

EDIT:

Nice System! +Rep! it is very very useful for me :D.
nope, that rule states that if the resource is not approved after been reviewed by a mod(or labeled needs fix), if within 7 days no changes is done to update the resource, it will be marked as "Rejected".

Top
