Multidimensional Table

--Maintaining multi-dimensional structures can be tedious: function setValue(key1,key2,key3,value) T[key1] = T[key1] or {} T[key1][key2] = T[key1][key2] or {} T[key1][key2][key3] = value end function getValue(key1,key2,key3) if T[key1] and T[key1][key2] then return T[key1][key2][key3] end return nil end

-- MDTable.create(numDimensions) -- creates a table that allows for direct access of the specified amount of dimensions. T = MDTable.create(3) --creates a multidimensional table with 3 dimensions T[1][2][Player(0)] = 42 print(T[1][2][Player(0)]) --prints "42" print(T[1][2][3]) --prints "nil", because no value has been assigned to the specified set of keys print(T[1][2][3][4]) --throws an error, because the MDTable has been created with 3 dimensions only.

-- for key_1, key_2, ..., key_n, value in pairs(T) do [doStuff] end T = MDTable.create(3) T[1]["bla"][1.5] = 42 for key1, key2, key3, value in pairs(T) do print(key1, key2, key3, value) --prints "1 bla 1.5 42" end

-- MDTable.create(numDimensions, defaultValue) T = MDTable.create(3, "Hello") print(T[1][2][3]) --prints "Hello". T[1][2][3] will still not contain a value (value isn't persisted). for key1, key2, key3, value in pairs(T) do print(key1, key2, key3, value) -- doesn't print anything, because T is still empty. end

local sumOfKeys = function(key1,key2,key3) return key1 + key2 + key3 end T = MDTable.create(3, sumOfKeys) print(T[1][2][3]) --prints "6" print(T[1]["bla"][5]) --throws an error, because the specified function wasn't able to deal with the string parameter.

-- MDTable.create(numDimensions, defaultValue, persistDefault_yn) T = MDTable.create(3, "Hello", true) --setting third parameter to true will permanently save default in the table upon read access print(T[1][2][3]) --prints "Hello". T[1][2][3] now contains "Hello" for key1, key2, key3, value in pairs(T) do print(key1, key2, key3, value) -- prints "1 2 3 Hello" end

function createDatatable(player, levelId) return {kills = 0, receivedGold = 0, playerName = GetPlayerName(player)} end T = MDTable.create(2, createDatatable, true) --2-dimensional table with function-type persisting default --Imagine we are in round 1 and want to increase the kill count for Player(0) by 1. T[Player(0)][1].kills = T[Player(0)][1].kills + 1 --works. Table access created the default value, persisted it and immediately allows for manipulating properties. for player, levelId, dataTable in pairs(T) do print(dataTable.kills, dataTable.playerName) --prints "1" and the name of Player(0). end

-- MDTable.create(numDimensions, defaultValue, persistDefault_yn, syncedLoop_yn) -- setting syncedLoop_yn to true makes the pairs-iteration synchronous in a multiplayer-game. This setting requires the SyncedTable-library. T = MDTable.create(3, "Hello", false, true) T[1][2][3] = "someValue" T["bla"][1.5][false] = "whatever" --Synced Loop for key1, key2, key3, value in pairs(T) do [you can change gamestate here] end

-- table.nestedSet(t, ... , value) -- Saves the specified value at the specified keys within t. Creates subtables, if necessary. --Example t = {} --We want to set t[1][2][3][4] = "Hello", table.nestedSet(t, 1, 2, 3, 4, "Hello") --automatically creates subtables in t[1] and t[1][2] etc., if not already present.

-- table.nestedGet(t, ...) -- Returns the value that t has stored at the specified keys. Returns nil, if any subtable is nil. --Example t = {} table.nestedSet(t, 1, 2, 3, 4, "Hello") -- t[1][2][3][4] = "Hello" print(table.nestedGet(t, 1, 2, 3, 4)) --prints "Hello" (the value at t[1][2][3][4]) print(table.nestedGet(t, 5, 6)) --prints "nil", because t[5] doesn't hold a subtable.

--Restrictions -- table.nestedSet will throw an error, if the specified key-path contains non-table values: t["error"] = 10 -- t["error"] already stores a value, so table.nestedSet throws an error. table.nestedSet(t, "error", "cantNestFurther", 20) --error -- The same holds for table.nestedGet table.nestedGet(t, "error", "cantNestFurther") --error

if Debug and Debug.beginFile then Debug.beginFile("MDTable") end --[[----------------------------------------------------------------------------------------------------------------------------------------------- * ------------------------------- * | Multidimensional Table v1.2 | * ------------------------------- * * by Eikonium * --> https://www.hiveworkshop.com/threads/multidimensional-table.353717/ * * - Multidimensional tables, short MDTables, are tables that allow for direct access of multiple table dimensions without the need of manual subtable creation. * - MDTables also provide the option of choosing a default value to be returned upon accessing non-existing keys. That default value is allowed to depend on the keys accessed. * - Finally, MDTables come with a custom pairs-iteration, which grants access to all combinations of keys that hold a value. See below for further details. * * MDTable.create(numDimensions: integer) --> table * - Standard use: * Creates an MDTable with the specified number of dimensions. E.g. "T = MDTable.create(3)" will allow you to read from and write to T[key1][key2][key3] for any arbitrary set of 3 keys. * You can think of it like a tree with constant depth that only allows you to write into the "leaf level" (using exactly the number of keys as dimensions specified). * - In the example with 3 dimensions, you should only write to T[key1][key2][key3], never to T[key1] or T[key1][key2]. * Reading is fine on every level, but you are probably not interested in the subtable stored in T[key1]. * You can however manually save further tables in T[key1][key2][key3] (at leaf level). * - MDTables will automatically create subtables on demand, i.e. upon reading from or writing to a combination of keys. * MDTable.create(numDimensions: integer, defaultValue: function|any) --> table * - Default Values: * Reading a nil value from the MDTable will instead return the specified defaultValue (which is nil, if not specified). * - Function-valued default value: * If defaultValue is a function, that function's return value will be returned. The function will be called with all requested keys as its arguments. * E.g. if T is an MDTable with 3 dimensions and defaultValue is a function, accessing an empty slot T[key1][key2][key3] will return defaultValue(key1,key2,key3). * MDTable.create(numDimensions: integer, defaultValue: function|any, persistDefault_yn: boolean) --> table * - Persisting default values: * When MDTables return the default values, they normally don't save it permanently. * You can make them do so by setting persistDefault_yn to true. * - Example: Let T be an MDTable with 3 dimensions, defaultValue = function(...) return {...} end, persistDefault_yn = true. * Now reading a nil-value at T[key1][key2][key3] will permanently save {key1,key2,key3} in that table slot. * MDTable.create(numDimensions: integer, defaultValue: function|any, persistDefault_yn: boolean, syncedLoop_yn: boolean) --> table * - Synced Loops: * Setting the syncedLoop_yn-parameter to true will make the iteration synchronous in multiplayer games (at the cost of some overhead), which prevents desyncs. * Hence it should be set to true, if and only if you plan to iterate over it in a multiplayer game. See comments on iteration below. * This setting requires the SyncedTable-library (https://www.hiveworkshop.com/threads/syncedtable.353715/). * * for key1, key2, ..., key_n, value in pairs(<MDTable>) do [doStuff] end * - You can iterate over an MDTable by using Lua's native pairs(). Loop-parameters are all keys plus the value at leaf level. * - Example: * local T = MDTable.create(3, 42) --creates an MDTable with 3 dimensions and default value 42. * T[1][2][3] = "Hello" * T[1]["bla"][Player(0)] = "World" * print(T[2][3][4]) --> prints the defaultValue "42", but doesn't add that value to the table. Hence, it will not be iterated below. * for key1, key2, key3, value in pairs(T) do * print(key1, key2, key3, value) --will print "1 2 3 Hello" and "1 bla Player(0) World" * end * - As all subtables of MDTables up to leaf level are also MDTables, you can iterate over subtables with the same method. Note that subtables have a lower dimension. * --Following the example from above * for key1, key2, value in pairs(T[1]) do * print(key1, key2, value) --> will print "2 3 Hello" * end * * ------------------------- * | nestedSet & nestedGet | * ------------------------- * * table.nestedSet(t, ..., value) * - Saves the specified value at the specified keys within t. Creates subtables, if necessary. * - E.g. nestedSet(t, 1, 2, 3) is equivalent to t[1][2] = 3 and will save a subtable in t[1], if not already present. * table.nestedGet(t, ...) * - Returns the value that t has stored at the specified keys. Returns nil, if any of subtable is nil. * - E.g. nestedGet(t, 1, 2) returns t[1][2] (or nil, if t[1] is nil). -------------------------------------------------------------------------------------------------------------------------------------------------]] -- disable sumneko extension warnings for imported resource ---@diagnostic disable do local nestedGet nestedGet = function(t, k, ...) if k == nil and select('#', ...) == 0 then return t elseif t[k] == nil then return nil end return nestedGet(t[k], ...) end ---Multidimensional get-operation. --- ---Returns the value from the specified table at the specified set of keys. ---E.g. table.nestedGet(t, 1,2,3) will return t[1][2][3]. ---If any of the subtables in the path are nil, table.nestedGet will return nil. ---Using this function frees you from checking every dimension for whether it contains a subtable or not. ---@param t table ---@param ... any keys to access from t ---@return any value table.nestedGet = function(t, ...) return nestedGet(t,...) end local nestedSet nestedSet = function(t, k, v, ...) if select('#', ...) == 0 then t[k] = v else if t[k] == nil then --don't use or-operator. Might overwrite false-key. t[k] = {} end nestedSet(t[k], v, ...) end end ---Multidimensional set-operation. --- ---Sets the table at the specified set of keys to the specified value. Creates subtables, where necessary. ---E.g. table.nestedSet(t, 1, 2, 3, 42) will set t[1][2][3] = 42 and create subtables at t[1] and t[1][2], if not already present. ---Using this function frees you from checking for existing subtables. ---@param t table ---@param ... any keys to access and value to set. The last parameter will be taken as the value. table.nestedSet = function(t, ...) nestedSet(t, ...) end MDTable = {} local unpack = table.unpack --Prepare table holding meta-information about every Multidimensional table and its subtables. --Every subtable has a depth - the base table starts at 1 and the value increases for 1 for each nested level. --The number of dimensions is referred to as maxDepth. It equals the depth at which the actual values are stored (instead of further subtables). --The user can choose a default value to be returned, when no value has been saved in a certain combination of keys before. Returning a default value will persist it in the table, if specified in the create-method. --SyncedTables also need to save their old __index and __pairs metamethods to allow the new methods to call those. local metaInfo = {} ---@type table<table,{depth:integer,maxDepth:integer,default:any,persistDefault:boolean,oldIndex:function,oldPairs:function}> ---------------------------------------- --| Implementation for normal tables |-- ---------------------------------------- -- MDTables have a different implementation for normal tables and SyncedTables. Normal tables use the class itself as their metatable. SyncedTables manipulate the metatable they already have. --The index-metamethod creates new subtables or returns the default-value, depending on which nested level the read access has been conducted. --As the same metatable is applied to all subtables, the parameter t can be any subtable on any level. MDTable.__index = function(t, key) local tMetaInfo = metaInfo[t] if tMetaInfo.depth == tMetaInfo.maxDepth then local default = tMetaInfo.default tMetaInfo[tMetaInfo.depth] = key --add current accessed key to the table to add it to the unpacking. This will be overwritten on every call, but doesn't matter. local defaultVal = (type(default) == 'function' and default(unpack(tMetaInfo, 1, tMetaInfo.depth))) or default --return default-value for full level read access if tMetaInfo.persistDefault then t[key] = defaultVal end return defaultVal else local newDim = {} --create new subtable on read access below full level t[key] = newDim --save subtable to requested key --prepare meta info for newDim local newMetaInfo = { default = tMetaInfo.default --pass default value from t to its new subtable , depth = tMetaInfo.depth + 1 --depth of subtable is 1 higher than depth of t (obviously) , maxDepth = tMetaInfo.maxDepth --pass max depth from t to subtable , persistDefault = tMetaInfo.persistDefault --pass information on whether to persist default value to subtable } --copy path of t to subtable for i = 1, tMetaInfo.depth - 1 do newMetaInfo[i] = tMetaInfo[i] end newMetaInfo[tMetaInfo.depth] = key --last key of the "path" to the new subtable metaInfo[newDim] = newMetaInfo setmetatable(newDim, MDTable) --apply same metatable to subtable return newDim --return new subtable, so the read access can continue as normal (and probably involves further nested calls of __index) end end --The pairs-metamethod is supposed to work for any number of dimensions, so we need recursion to get to a full level set of keys holding a value on max level. local loopRecursion ---Recursive loop for Nested Tables used by the iterator function for Multidimensinal Table. ---The loop reads all combinations of keys that hold a value on max level, returns that combination to the iterator and pauses the loop using coroutines, until the iterator resumes it. ---@param t table t can be any subtable, it's a recursion after all ---@param syncedLoop_yn boolean true, if loop is conducted on a multidimensional SyncedTable ---@param returnVals table holds all keys that the recursion has already gone through, so that they can be passed via table.unpack on demand ---@param loopLevel integer dimension at which the recursion is currently operating. Equals the subtable depth in case the pairs-function was used on the base table. loopRecursion = function(t, syncedLoop_yn, returnVals, loopLevel) local tMetaInfo = metaInfo[t] local iter, state --iterator to be used depends on whether we deal with a normal table or a SyncedTable. if syncedLoop_yn then iter, state = tMetaInfo.oldPairs() else iter, state = next, t end local k, v = iter(state) --first key-value-pair to loop through at the current loop level --if t sits below max level, we loop through all (key,subtable)-pairs of t. if tMetaInfo.depth < tMetaInfo.maxDepth then while k ~= nil do --"while k do" won't do it - k can be "false". returnVals[loopLevel] = k --remember the key in the returnVals table loopRecursion(v, syncedLoop_yn, returnVals, loopLevel + 1) --every subtable must conduct a full loop itself k, v = iter(state, k) --get next key-subtable-pair end else --if t sits at max level, we loop through all (key,value)-pairs of t. while k ~= nil do returnVals[loopLevel] = k --remember the key in the returnVals table returnVals[loopLevel+1] = v --at max level, also remember the value coroutine.yield(unpack(returnVals, 1, loopLevel+1)) --return the complete set of keys plus final value to the iterator and pause the loop until further request k, v = iter(state, k) --get next key-value-pair end end --when the first call of the recursive loop ends, all inner recursion has already finished -> fo a final yield on the coroutine to put it to dead state if loopLevel == 1 then coroutine.yield() end end --Define behaviour of the pairs-function for Multidimensional tables based on normal tables. --The pairs-function is supposed to loop through all combinations of keys that hold a value at max level. --It enables the following syntax: for key1, key2, ..., key_n, value in pairs(T) do ... end MDTable.__pairs = function(t) local cor = coroutine.create(loopRecursion) --we need a coroutine to pause the loop recursion between every request of the iterator function local returnVals = {} --table to hold all return values for this specific loop. Passed to the recursion. return function() --successful coroutine calls return true plus the yielded values, so we need to return everything after the first value return select(2,coroutine.resume(cor, t, false, returnVals, 1)) end, t, nil end --Allows to call the Multidimensional table directly via T(key1,key2,...,key_n) MDTable.__call = function(t, ...) return table.nestedGet(t, ...) end --------------------------------------- --| Implementation for SyncedTables |-- --------------------------------------- --SyncedTables need special treatment, as they all have their own individual metatable with __index and __pairs already defined. --We basically define new index and pairs for the SyncedTable by using the old instance. local prepareSyncedTable local syncedIndex = function(t, key) local tMetaInfo = metaInfo[t] local oldIndexVal = tMetaInfo.oldIndex(t, key) --if the SyncedTable holds a value for the given key, return that value if oldIndexVal then return oldIndexVal --return default value, if there is no stored value and the user is reading at max level elseif tMetaInfo.depth >= tMetaInfo.maxDepth then local default = tMetaInfo.default tMetaInfo[tMetaInfo.depth] = key --add current accessed key to tMetaInfo to add it to the unpacking below. The key at full depth will be overwritten on every call, but doesn't matter. local defaultVal = (type(default) == 'function' and default(unpack(tMetaInfo, 1, tMetaInfo.depth))) or default if tMetaInfo.persistDefault then t[key] = defaultVal --triggers SyncedTable newIndex metamethod end return defaultVal --create sub-SyncedTable, if not already present and reading below max level else local newDim = SyncedTable.create() t[key] = newDim --don't use rawset. This must trigger SyncedTable __newindex to work. local newMetaInfo = { default = tMetaInfo.default , depth = tMetaInfo.depth + 1 , maxDepth = tMetaInfo.maxDepth , persistDefault = tMetaInfo.persistDefault } metaInfo[newDim] = newMetaInfo prepareSyncedTable(newDim) --again manipulate metatables of new SyncedTable --copy path from tMetaInfo to newMetaInfo for i = 1, tMetaInfo.depth - 1 do newMetaInfo[i] = tMetaInfo[i] end newMetaInfo[tMetaInfo.depth] = key return newDim end end --Define multidimensional pairs-function. Uses the same loopRecursion as for MDTables based on normal tables. local syncedPairs = function(t) local cor = coroutine.create(loopRecursion) local returnVals = {} return function() --successful coroutine calls return true plus the yielded values, so we need to return everything after the first value return select(2,coroutine.resume(cor, t, true, returnVals, 1)) end, t, nil end ---Manipulates the metatable of a SyncedTable in a way that it allows for nested access. ---Writes into metaInfo[t], so requires that table to already exist. ---@param t table actually SyncedTable, but we don't mention the true type to prevent "undefined type" errors, when SyncedTables is not being used (optional dependency). prepareSyncedTable = function(t) local mt = getmetatable(t) --original metatable of the SyncedTable to be manipulated local tMetaInfo = metaInfo[t] tMetaInfo.oldIndex = mt.__index --original __index tMetaInfo.oldPairs = mt.__pairs --original __pairs-function must be saved somewhere to be accessible from within the loop recursion --SyncedTable __index triggers on every read action, because the table itself is kept empty by design. That means we must also deal with the case where the SyncedTable actually holds a value for the requested key. mt.__index = syncedIndex mt.__pairs = syncedPairs mt.__call = MDTable.__call end ---Create a new Multidimensional Table. ---@param numDimensions integer number of dimensions accessible on the new Multidim Table ---@param defaultValue? function|any default: nil. Default value to return at leaf level access, when the requested combination of keys has no value assigned. If function: calls that function and uses its return value. ---@param persistDefault_yn? boolean default: false. set to true to persist the default value in the table at the requested combination of keys upon read access, when there wasn't yet any value assigned. ---@param syncedLoop_yn? boolean default: false. set to true to allow for multiplayer-synced pairs-loop. Requires SyncedTable. Set to false, if you create a singleplayer game or if you don't plan to loop over this table. ---@return table MDTable.create = function(numDimensions, defaultValue, persistDefault_yn, syncedLoop_yn) local newTable --If user desires synced loop and the SyncedTable-library is present, create SyncedTable and manipulate its metatables. if syncedLoop_yn and SyncedTable then newTable = SyncedTable.create() metaInfo[newTable] = {} prepareSyncedTable(newTable) --manipulating existing metatable instead of assigning the class as metatable. else --If user desires normal loop or no loop, create normal table and set standard metatable. newTable = {} metaInfo[newTable] = {} setmetatable(newTable, MDTable) end metaInfo[newTable].depth = 1 --the base table has depth 1 metaInfo[newTable].maxDepth = numDimensions --maxdepth is the dimension chosen by the user metaInfo[newTable].default = defaultValue --default value for max level access metaInfo[newTable].persistDefault = persistDefault_yn --tells, if the default value shall be saved upon read access return newTable end end if Debug and Debug.endFile then Debug.endFile() end

Eikonium

Patron

Level 23

Resources: 15

May 7, 2024

This resource has been moved here from the old Code forum. You can find the old discussion in this thread.

Antares

Spell Reviewer

Level 32

Resources: 44

May 7, 2024

Originally approved by @Bribe :

"This is a very powerful resource and enables tables to go into any desired depth with ease, and with multiple flavor options to choose from. As usual, the code and API is well-designed, flushed out and rich in content and utility.

Approved."

Approved

Regno

Level 8

Nov 28, 2024

For some odd reason, I get this error:

Got both MDTable and SyncedTable imported, tried having SyncedTable above and below MDTable, but still the same result regarding the error.

SyncedTable ver: v1.1b
MDTable ver: v1.1

With this code:

Lua:

    T = MDTable.create(3, "Hello", false, true)
    T[1][2][3] = "someValue"
    T["bla"][1.5][false] = "whatever"
    --Synced Loop
    for key1, key2, key3, value in pairs(T) do
        print(key1, key2, key3, value)
    end
