Fire Spread 1.2

[Moderator]

Approved

Good and interesting system.

It could benefit from having configurable values fo burn duration,
burn chance etc.
The timer could run a bit less often, it doesn't need to run every 0.05 seconds.



[Zanekok]

Triggers

• Initialising
  • Events
    • Map initialization
  • Conditions
  • Actions
    • Set Var_Damage = 1.00
    • -------- Damage dealt to burning destructible every tick of "Burned out" --------
    • Set Var_Timer = 5.00
    • -------- Time one destructible is in fire. (in seconds) --------
    • Set Var_Range = 500.00
    • -------- Range in which fire can spread. --------
    • Visibility - Disable black mask
    • Visibility - Disable fog of war

• Fire
  • Events
    • Unit - A unit Starts the effect of an ability
  • Conditions
    • (Ability being cast) Equal to Eager Fire (Naisha)
  • Actions
    • If (All Conditions are True) then do (Then Actions) else do (Else Actions)
      • If - Conditions
        • Fire_Integer[1] Equal to 0
      • Then - Actions
        • Trigger - Turn on Burned out <gen>
      • Else - Actions
    • Set Fire_Integer[1] = (Fire_Integer[1] + 1)
    • Set Fire_Integer[2] = (Fire_Integer[2] + 1)
    • Set Fire_Damage[Fire_Integer[2]] = Var_Damage
    • Set Fire_Timer[Fire_Integer[2]] = Var_Timer
    • Set Fire_Destructible[Fire_Integer[2]] = (Target destructible of ability being cast)
    • Set Fire_SfxString[Fire_Integer[2]] = Doodads\Cinematic\TownBurningFireEmitter\TownBurningFireEmitter.mdl
    • Set Fire_Bonusfx[Fire_Integer[2]] = Objects\Spawnmodels\Other\NeutralBuildingExplosion\NeutralBuildingExplosion.mdl
    • Set Fire_Point = (Position of Fire_Destructible[Fire_Integer[2]])
    • Special Effect - Create a special effect at Fire_Point using Fire_SfxString[Fire_Integer[2]]
    • Set Fire_Effect[Fire_Integer[2]] = (Last created special effect)
    • Set Fire_Boolean[Fire_Integer[2]] = True
    • Custom script: call RemoveLocation (udg_Fire_Point)

• Burned out
  • Events
    • Time - Every 0.10 seconds of game time
  • Conditions
  • Actions
    • For each (Integer Fire_Integer[3]) from 1 to Fire_Integer[2], do (Actions)
      • Loop - Actions
        • If (All Conditions are True) then do (Then Actions) else do (Else Actions)
          • If - Conditions
            • Fire_Boolean[Fire_Integer[3]] Equal to True
          • Then - Actions
            • Destructible - Set life of Fire_Destructible[Fire_Integer[3]] to ((Current life of Fire_Destructible[Fire_Integer[3]]) - Fire_Damage[Fire_Integer[3]])
            • Set Fire_Timer[Fire_Integer[3]] = (Fire_Timer[Fire_Integer[3]] - 0.10)
            • If (All Conditions are True) then do (Then Actions) else do (Else Actions)
              • If - Conditions
                • Or - Any (Conditions) are true
                  • Conditions
                    • (Fire_Destructible[Fire_Integer[3]] is dead) Equal to True
                    • Fire_Timer[Fire_Integer[3]] Less than or equal to 0.00
              • Then - Actions
                • Set Fire_Boolean[Fire_Integer[3]] = False
                • Set Fire_Timer[Fire_Integer[3]] = 0.00
                • Set Fire_Destructible[Fire_Integer[3]] = No destructible
                • Set Fire_SfxString[Fire_Integer[3]] = <Empty String>
                • Set Fire_Bonusfx[Fire_Integer[3]] = <Empty String>
                • Special Effect - Destroy Fire_Effect[Fire_Integer[3]]
                • Set Fire_Integer[1] = (Fire_Integer[1] - 1)
                • If (All Conditions are True) then do (Then Actions) else do (Else Actions)
                  • If - Conditions
                    • Fire_Integer[1] Equal to 0
                  • Then - Actions
                    • Set Fire_Integer[2] = 0
                    • Trigger - Turn off (This trigger)
                  • Else - Actions
              • Else - Actions
                • Set Fire_Chance[Fire_Integer[3]] = (Random integer number between 1 and 10)
                • If (All Conditions are True) then do (Then Actions) else do (Else Actions)
                  • If - Conditions
                    • (Current life of Fire_Destructible[Fire_Integer[3]]) Less than ((Max life of Fire_Destructible[Fire_Integer[3]]) x 0.50)
                    • Fire_Chance[Fire_Integer[3]] Equal to 1
                  • Then - Actions
                    • Set Temp_point = (Position of Fire_Destructible[Fire_Integer[3]])
                    • Set Temp_region = (Region centered at Temp_point with size (Var_Range, Var_Range))
                    • Set Temp_tree = (Random destructible in Temp_region matching ((((Matching destructible) is dead) Equal to False) and ((Matching destructible) Not equal to Fire_Destructible[Fire_Integer[3]])))
                    • If (All Conditions are True) then do (Then Actions) else do (Else Actions)
                      • If - Conditions
                        • Temp_tree Not equal to No destructible
                      • Then - Actions
                        • Set Fire_Integer[1] = (Fire_Integer[1] + 1)
                        • Set Fire_Integer[2] = (Fire_Integer[2] + 1)
                        • Set Fire_Damage[Fire_Integer[2]] = Var_Damage
                        • Set Fire_Destructible[Fire_Integer[2]] = Temp_tree
                        • Set Fire_Timer[Fire_Integer[2]] = Var_Timer
                        • Set Fire_SfxString[Fire_Integer[2]] = Doodads\Cinematic\TownBurningFireEmitter\TownBurningFireEmitter.mdl
                        • Set Fire_Bonusfx[Fire_Integer[2]] = Objects\Spawnmodels\Other\NeutralBuildingExplosion\NeutralBuildingExplosion.mdl
                        • Set Fire_Point = (Position of Fire_Destructible[Fire_Integer[2]])
                        • Special Effect - Create a special effect at Fire_Point using Fire_SfxString[Fire_Integer[2]]
                        • Set Fire_Effect[Fire_Integer[2]] = (Last created special effect)
                        • Set Fire_Boolean[Fire_Integer[2]] = True
                        • Custom script: call RemoveLocation (udg_Fire_Point)
                      • Else - Actions
                    • Set Fire_Chance[Fire_Integer[3]] = (Random integer number between 1 and 10)
                    • If (All Conditions are True) then do (Then Actions) else do (Else Actions)
                      • If - Conditions
                        • Fire_Chance[Fire_Integer[3]] Equal to 10
                      • Then - Actions
                        • Special Effect - Create a special effect at Temp_point using Fire_Bonusfx[Fire_Integer[3]]
                        • Special Effect - Destroy (Last created special effect)
                      • Else - Actions
                    • Set Fire_Chance[Fire_Integer[3]] = 0
                    • Custom script: call RemoveRect (udg_Temp_region)
                    • Custom script: call RemoveLocation (udg_Temp_point)
                  • Else - Actions
          • Else - Actions

You have full rights to edit this and use it! I won't update this cause i don't know anymore how it works! If you make better version just upload it!

EDIT: Due to comment of MOD I'll try to rework it, cause right now i have nothing to do.
EDIT2: OK Updated



[Karzama]

It would be good if it went across buildings too (Or there was a separate version that went over buildings rather than destructibles)



[Zanekok]

It would be good if it went across buildings too (Or there was a separate version that went over buildings rather than destructibles)

Separated version would be too easy. This was much more challenging. I was doing this cause of challenge



[Karzama]

So does it spread to buildings as well as descructables?



[gorillabull]

nice spell



[Zanekok]

Write me what you want to upgrade. I've forgotten something important maybe



[Wareditor]

Interesting !



[khamarr3524]

I recommend using an array to check the destructable type for configuration purposes. What if you have 80 destructable types you want to be flammable?



[Zanekok]

khamarr this is better anyway. If it would be in array i would have to make another loop that would make this more laggy. And you would have to write it to that array anyway. So this is really much much better
