Is Point Pathable

Arhowk · Feb 5, 2012

is there a thing? there is in jass (IsTerrainPathable)

Cokemonkey11 · Feb 5, 2012

You just answered your own question.

Use GetLocationX() and GetLocationY() if you want to use a point as the perameters.

Arhowk · Feb 5, 2012

Cokemonkey11 said:
You just answered your own question.

Use GetLocationX() and GetLocationY() if you want to use a point as the perameters.

I meant in GUI

Cokemonkey11 · Feb 5, 2012

If you're working with things like pathing maps, you should not be using GUI.

Arhowk · Feb 5, 2012

Cokemonkey11 said:
If you're working with things like pathing maps, you should not be using GUI.

no im spawning in a random point in region but its glitching because its spawning in unpathable points

Cokemonkey11 · Feb 5, 2012

Please excuse me for not linking the original, but here's IsTerrrainWalkable from one of my maps -

JASS:

//Thanks to anitarf and Vexorian @ wc3c.net for this library, it makes things easier.

library IsTerrainWalkable initializer Init
    globals
        // this value is how far from a point the item may end up for the point to be considered pathable
        private constant real MAX_RANGE=10.
        // the following two variables are set to the position of the item after each pathing check
        // that way, if a point isn't pathable, these will be the coordinates of the nearest point that is
        public real X=0.
        public real Y=0.
        private rect r
        private item check
        private item array hidden
        private integer hiddenMax=0
    endglobals

    private function Init takes nothing returns nothing
        set check=CreateItem('ciri',0,0)
        call SetItemVisible(check,false)
        set r=Rect(0.0,0.0,128.0,128.0)
    endfunction

    private function HideBothersomeItem takes nothing returns nothing
        if IsItemVisible(GetEnumItem()) then
            set hidden[hiddenMax]=GetEnumItem()
            call SetItemVisible(hidden[hiddenMax],false)
            set hiddenMax=hiddenMax+1
        endif
    endfunction

    function IsTerrainWalkable takes real x, real y returns boolean
        // first, hide any items in the area so they don't get in the way of our item
        call MoveRectTo(r,x,y)
        call EnumItemsInRect(r,null,function HideBothersomeItem)
        // try to move the check item and get it's coordinates
        call SetItemPosition(check,x,y)//this unhides the item...
        set X=GetItemX(check)
        set Y=GetItemY(check)
        call SetItemVisible(check,false)//...so we must hide it again
        // before returning, unhide any items that got hidden at the start
        loop
            exitwhen hiddenMax<=0
            set hiddenMax=hiddenMax-1
            call SetItemVisible(hidden[hiddenMax],true)
            set hidden[hiddenMax]=null
        endloop
        // return pathability status
        return (x-X)*(x-X)+(y-Y)*(y-Y)<MAX_RANGE*MAX_RANGE
    endfunction
endlibrary

Arhowk · Feb 5, 2012

Cokemonkey11 said:

Please excuse me for not linking the original, but here's IsTerrrainWalkable from one of my maps -

JASS:

//Thanks to anitarf and Vexorian @ wc3c.net for this library, it makes things easier.

library IsTerrainWalkable initializer Init
    globals
        // this value is how far from a point the item may end up for the point to be considered pathable
        private constant real MAX_RANGE=10.
        // the following two variables are set to the position of the item after each pathing check
        // that way, if a point isn't pathable, these will be the coordinates of the nearest point that is
        public real X=0.
        public real Y=0.
        private rect r
        private item check
        private item array hidden
        private integer hiddenMax=0
    endglobals

    private function Init takes nothing returns nothing
        set check=CreateItem('ciri',0,0)
        call SetItemVisible(check,false)
        set r=Rect(0.0,0.0,128.0,128.0)
    endfunction

    private function HideBothersomeItem takes nothing returns nothing
        if IsItemVisible(GetEnumItem()) then
            set hidden[hiddenMax]=GetEnumItem()
            call SetItemVisible(hidden[hiddenMax],false)
            set hiddenMax=hiddenMax+1
        endif
    endfunction

    function IsTerrainWalkable takes real x, real y returns boolean
        // first, hide any items in the area so they don't get in the way of our item
        call MoveRectTo(r,x,y)
        call EnumItemsInRect(r,null,function HideBothersomeItem)
        // try to move the check item and get it's coordinates
        call SetItemPosition(check,x,y)//this unhides the item...
        set X=GetItemX(check)
        set Y=GetItemY(check)
        call SetItemVisible(check,false)//...so we must hide it again
        // before returning, unhide any items that got hidden at the start
        loop
            exitwhen hiddenMax<=0
            set hiddenMax=hiddenMax-1
            call SetItemVisible(hidden[hiddenMax],true)
            set hidden[hiddenMax]=null
        endloop
        // return pathability status
        return (x-X)*(x-X)+(y-Y)*(y-Y)<MAX_RANGE*MAX_RANGE
    endfunction
endlibrary

getting error : Undeclared Function IsTerrainWalkable from this if (IsTerrainWalkable(GetLocationX(udg_TempLoc), GetLocationY(udg_TempLoc))) then < -.- i have that snippet in map why is it not work

Magtheridon96 · Feb 6, 2012

Try removing the library/endlibrary lines, then change the function Init's name to InitTrig_TerrainWalkable, then put it in the Map header.

Arhowk · Feb 6, 2012

Magtheridon96 said:
Try removing the library/endlibrary lines, then change the function Init's name to InitTrig_TerrainWalkable, then put it in the Map header.

private outside lbrary/scope definition. Im having this trouble (undeclared function) with another function too, i dont understand why!

Cokemonkey11 · Feb 6, 2012

If you're getting that error, sounds like you DO have JNGP.

What was the error with the first script? before doing what magtheridon said, that is.

Arhowk · Feb 6, 2012

Cokemonkey11 said:
If you're getting that error, sounds like you DO have JNGP.

What was the error with the first script? before doing what magtheridon said, that is.

Ya think? lol. The error with the first script, after importing it, was "Undeclared Function : IsTerrainWalkable"

Cokemonkey11 · Feb 6, 2012

After importing it? Just put it in an empty trigger called "IsTerrainWalkable".

Then use IsTerrainWalkable(x,y) as a custom script elsewhere.

Arhowk · Feb 6, 2012

Cokemonkey11 said:
After importing it? Just put it in an empty trigger called "IsTerrainWalkable".

Then use IsTerrainWalkable(x,y) as a custom script elsewhere.

Nope.

i put it in a trigger called IsTerrainWalkable and did
if ( IsTerrainWalkable(GetLocationX(udg_TempLoc) , GetLocationY(udg_TempLoc)) ) == true then

and it still says Undeclared Function IsTerrainWalkable

Cokemonkey11 · Feb 6, 2012

You should be writing jass triggers, not using custom scripts

You can convert this library to non-vJass but the effort is not worth it.

You have JNGP. You obviously have at least a beginner's knowledge of jass.

It's time to switch. PM me if you want help.

Arhowk · Feb 6, 2012

Cokemonkey11 said:
You should be writing jass triggers, not using custom scripts

You can convert this library to non-vJass but the effort is not worth it.

You have JNGP. You obviously have at least a beginner's knowledge of jass.

It's time to switch. PM me if you want help.

What? the trigger thats using that function is in JASS not GUI, i have no idea what your talking about.

Cokemonkey11 · Feb 6, 2012

Please, show me the trigger.

Arhowk · Feb 6, 2012

JASS:

library GetPathablePoint
function GetPathablePointInRect takes rect r returns nothing
    set udg_TempInt = 1
    loop
        exitwhen udg_TempInt > 10
        set udg_TempLoc = GetRandomLocInRect(r)
        if (IsTerrainWalkable(GetLocationX(udg_TempLoc), GetLocationY(udg_TempLoc))) == true then
            set udg_TempInt = 10
        else
            set udg_TempInt = 1
        endif
        set udg_TempInt = udg_TempInt + 1
    endloop
endfunction
endlibrary

Cokemonkey11 · Feb 6, 2012

JASS:

library GetPathablePoint requires IsTerrainWalkable
    function GetPathablePointInRect takes rect r returns location
        local location loc
        local real randX=GetRectCenterX(r)
        local real randY=GetRectCenterY(r)
        loop
            exitwhen IsTerrainWalkable(randX,randY)
            set randX=GetRandomReal(GetRectMinX(r),GetRectMaxX(r))
            set randY=GetRandomReal(GetRectMinY(r),GetRectMaxY(r))
        endloop
        set Loc=Location(loc,randX,randY)
        return loc
    endfunction
endlibrary

NB: If the given rect contains no walkable points, the thread will crash.

Arhowk · Feb 6, 2012

Cokemonkey11 said:

JASS:

library GetPathablePoint requires IsTerrainWalkable
    function GetPathablePointInRect takes rect r returns location
        local location loc
        local real randX=GetRectCenterX(r)
        local real randY=GetRectCenterY(r)
        loop
            exitwhen IsTerrainWalkable(randX,randY)
            set randX=GetRandomReal(GetRectMinX(r),GetRectMaxX(r))
            set randY=GetRandomReal(GetRectMinY(r),GetRectMaxY(r))
        endloop
        set Loc=Location(loc,randX,randY)
        return loc
    endfunction
endlibrary

NB: If the given rect contains no walkable points, the thread will crash.

Now im suspicous....

Undeclared Variable Loc

um..? all i did was remove the Loc, from Set Loc=Location(randX,randY)

Cokemonkey11 · Feb 6, 2012

Excuse me, this line:

JASS:

set Loc=Location(loc,randX,randY)

should have said:

JASS:

set loc=Location(randX,randY)

gorillabull · Feb 6, 2012

i think THE TIME HAS COME for you to start using MIGHTY MIGHTY jass and quit noob GUI
the first think you can do is to start converting the trigger and learning the function syntax

Magtheridon96 · Feb 6, 2012

Awww, but I just finished writing a vanilla Jass version of the script so you can paste it in the map header

JASS:

    // Required Globals
    // Create these globals using the variable editor

    //real         TW_MAX_RANGE
    //real         TW_X
    //real         TW_Y
    //rect         TW_r
    //item         TW_check
    //item array   TW_hidden
    //integer      TW_hiddenMax

    function HideBothersomeItem takes nothing returns nothing
        if IsItemVisible(GetEnumItem()) then
            set udg_TW_hidden[udg_TW_hiddenMax] = GetEnumItem()
            call SetItemVisible(udg_TW_hidden[udg_TW_hiddenMax], false)
            set udg_TW_hiddenMax = udg_TW_hiddenMax + 1
        endif
    endfunction

    function IsTerrainWalkable takes real x, real y returns boolean

        call MoveRectTo(udg_TW_r, x, y)
        call EnumItemsInRect(udg_TW_r, null, function HideBothersomeItem)

        call SetItemPosition(udg_TW_check, x, y)//this unhides the item...
        set udg_TW_X=GetItemX(udg_TW_check)
        set udg_TW_Y=GetItemY(udg_TW_check)
        call SetItemVisible(udg_TW_check, false)//...so we must hide it again

        loop
            exitwhen udg_TW_hiddenMax <= 0
            set udg_TW_hiddenMax = udg_TW_hiddenMax - 1
            call SetItemVisible(udg_TW_hidden[udg_TW_hiddenMax], true)
            set udg_TW_hidden[udg_TW_hiddenMax] = null
        endloop

        return (x - udg_TW_X) * (x - udg_TW_X) + (y - udg_TW_Y) * (y - udg_TW_Y) < udg_TW_MAX_RANGE * udg_TW_MAX_RANGE
    endfunction

    function InitTrig_initTerrainWalk takes nothing returns nothing
        set udg_TW_MAX_RANGE = 10
        set udg_TW_X = 0
        set udg_TW_Y = 0
        set udg_TW_r = Rect(0, 0, 128, 128)
        set udg_TW_check = CreateItem('ciri', 0, 0)
        call SetItemVisible(udg_TW_check, false)
        set udg_TW_hiddenMax = 0
    endfunction

Cokemonkey11 · Feb 6, 2012

vanilla jass
