How to extract game files


Introduction

Extracting game files is not something everyone will need, but those who would can need them for many things: you may need to get some data from the game SLKs, get a function's definition from the blizzard's code files, get a file to modify and use in your map or with local files.

This tutorial will have instructions for both MPQ (Warcraft 3 patches before 1.30 and from maps) and CASC (Warcraft 3 patches 1.30+), and will outline which MPQs and CASC roots contain which files.



What are MPQs?

MPQ is an archive format made by Blizzard, similar in some aspects to a ZIP file. They are used both to store map files (w3m and w3x files are MPQs, sometimes with an extra header), custom campaign files (w3n files are also MPQs), and game files until 1.29.2. More technical information can be found here.

MPQ files' contents

There were 4 main game MPQs: War3.mpq, War3Local.mpq, War3x.mpq, War3xLocal.mpq; note that these are not the only files the game would look in when loading a file.

War3.mpq contained all the game files that were not TFT-only and did not change based on the game's locallization (translation, for example sounds and text).

War3Local.mpq contained the localized files that were not TFT-only.

War3x.mpq contained all the game files that were TFT-only but did not change based on the game's locallization.

War3xLocal.mpq contained the localized files that were TFT-only.

There was also War3Patch.mpq that used to stored all files that were updated with patches, but it has been removed after 1.28.

Inside of the main MPQs, there were also MPQs for every tileset (called like A.mpq, with A being the tileset character specified in the w3i) and for low and medium graphics modes (war3_med.mpq and war3_low.mpq).


When loading a file from a system with MPQs, the data sources were considered as such (only specifying the main ones in this tutorial):

Local filesif local files are enabled

Map archive

Tileset MPQ

War3xLocal
if the map was loaded in TFT mode

War3x
if the map was loaded in TFT mode

War3Local

War3


How to extract from MPQs

There are many MPQ editors, but I personally recommend the one by Ladislav Zezula. It has the option to open one or multiple MPQs at once, automatically recognizes extensions of files not covered with a listfile (most files in Warcraft 3 patch MPQs), and can even make an MPQ from scratch or from a folder.
It will also give you the option to set it as the default handler for MPQs, so opening the game files becomes as simple as a double-click on the MPQ.​


What is CASC?

CASC is a system of storing game files, serving as a replacement for game MPQs. More in-depth information can be found here.​


CASC contents

CASC is a simpler system, being unified as opposed to the many MPQs of the old one.
war3.w3mod: the main root
_balance/*.w3mod: balance-related files, for any particular map the usage of these is dictated by "Game Data Set" and "Game Data Version"
_deprecated.w3mod: files that should no longer be used by anything but kept for backwards compatibility
_hd.w3mod: the root for HD files
_locales/*.w3mod: language-dependent file overrides for HD
_teen.w3mod: teen asset mode files for HD
_tilesets/*.w3mod: tileset-dependent files for HD​
_locales/*.w3mod: language-dependent files
_teen.w3mod: teen asset mode files
_tilesets/*.w3mod: tileset-dependent files

Maps can also have most of the subroots that war3.w3mod can have.

The hierarchy that will be outlined below is adjusted for latest version, but will be similar to the hierarchies of the older patches (not including locale and balance roots nor the teen [low violence mode] root, and the * in tileset names only means the active tileset, not every one of them):

Local filesif local files are enabled

Map archive:_hd.w3mod:_tilesets/*.w3mod
if HD mode is enabled

Map archive:_hd.w3mod
if HD mode is enabled

Map archive:_tilesets/*.w3mod

Map archive

war3.w3mod:_hd.w3mod:_tilesets/*.w3mod
if HD mode is enabled

war3.w3mod:_hd.w3mod
if HD mode is enabled

war3.w3mod:_tilesets/*.w3mod

war3.w3mod

How to extract from CASC
The only tool that can extract files from CASC is Ladislav Zezula's CascView. You will have to select either a game folder or game from a list. Getting the files from CASC is very similar to getting the files from MPQs from this point on.

Closing words

In both MPQ can CASC, files have similar paths accounting for roots:

abilitiesability and weapon models

buildings
building models

campaign
campaign maps

doodads
doodads models and data

environment
miscellaneous models and foliage data

fonts
fonts

maps
all melee and custom maps included with the game, they were
in the main Warcraft III folder(not in an mpq) in the MPQ system

movies
all pre-rendered cutscenes

objects
more miscellaneous models

pathtextures
object pathing maps

replaceabletextures
too many things to list in a table

scripts
code files: ai, jass and preload

shaders
3d graphics' shaders

sharedmodels
more miscellaneous models

sound
audio files

splats
splat data

terrainart
terrain models and data

textures
most of the game textures

ui
ui data, models, and textrues

units
unit models, and data for most objects

webui
webui (pre-game UI for 1.32+) files

Last edited:

Chaosy

Tutorial Reviewer
Level 38
Joined
Jun 9, 2011
Messages
13,059
Sorry about being late to check this one out.

Wouldn't you say this is too simple?
I have not tried this with Warcraft 3, but I have extracted wow models from casc with the suggested program. I think the process is identical.

The tutorial is more or less:
1. Download the program
2. open the mpq/casc
3. find your file and right click>extract

Or, realistically:
1. use the program

It's pretty obvious how to use the program if you are remotely tech-savvy.

You offer potentially interesting and useful information outside of the main steps but I don't think it belongs in a tutorial.

Level 6
Joined
Feb 25, 2013
Messages
57
I would agree it's very simple, but people too often don't want to look into any changes to the files, trying to use the MPQ editor on 1.30 and having no idea what to open with it; I have also added the folder structure to make the tutorial more comprehensive just so people who aren't too scared to try the tools themselves still have something to gain from reading the one post without having to search for more. The file loading hierarchies are also probably niche enough not to need a tutorial since people who need them can probably research them themselves or ask in the discord (link here in case some random person reads this and doesn't know we have it).

The root cause for me even writing this tutorial is the amount of people needing help in various Warcraft 3 discords with the most basic extraction, and I believe I still kept it less oversimplified than some of the older approved tutorials for it.

  • Like
Reactions: pyf

Chaosy

Tutorial Reviewer
Level 38
Joined
Jun 9, 2011
Messages
13,059
I would agree it's very simple, but people too often don't want to look into any changes to the files, trying to use the MPQ editor on 1.30 and having no idea what to open with it

I disagree.

If I have a tech problem in general, what is the first thing I do?
Google.


The thread: Where the heck is the .mpq?
This gives you enough info.
The same would probably happen if you used the site search functionality.

I agree there probably should exist a section with "useful tips" or something like that for things like this where the information is useful but is not worth taking up a tutorial slot (it's annoying to go through many pages if it starts to get bloated)

I have also added the folder structure to make the tutorial more comprehensive just so people who aren't too scared to try the tools themselves still have something to gain from reading the one post without having to search for more. The file loading hierarchies are also probably niche enough not to need a tutorial since people who need them can probably research them themselves or ask in the discord
I think you're having the opposite effect.
If I was intending to learn something and I go to the tutorial and see an a4 page worth of fairly compact information I would probably be discouraged and think it's something advanced.
I cannot prove this one way or the other so I'll leave that be.

But as I said in the first post, the extra stuff you added might be useful.
But not to the extent where I think it compensates for what I think is an unnecessary tutorial.
If a returning modder becomes confused, he can google/hive search it or ask in discord he gets the reply "You need another program in later patches" he downloads the program and he is basically good to go.

I think that a tutorial should give answers that are too complex or lengthy to be reasonably answered on a common basis by those willing to help.

If you disagree with this you are welcome to poke an admin or someone else on the staff team for a second opinion as the rule "too simple" is ultimately subjective.

Level 6
Joined
Feb 25, 2013
Messages
57
The only problem with that whole reply I see is that people wouldn't know "casc" is the word to search for, other than that I fully agree - people who won't google these kinds of issues have infinitesimal chances of finding this kind of a tutorial so it's useless to that group, and those that would google stuff can just do that instead.

All the extra data I put in is probably just feature-creep and you're correct that it makes the tutorial seem so much larger and more complicated than it is.

Also no need to poke anyone since I trust your opinions more on this, especially with me not having a good idea of the vision for the tutorial section. I guess one of the causes of this tutorial was also the amount of outdated and/or duplicate tutorials about extracting from MPQ and similar but making just one more pointless tutorial will by itself not change that.

As a last paragraph, sorry if any of these replies seem in any way attacking. English is not my native language so I might not conceive the context of some phrases or words. Thank you for your time :peasant-cheers-back:
