Heal Engine 1.0.3
- Author(s)
- Marchombre
- Tags
- GUI / Triggers, vJASS, System
- Size
- 112.71 KB
- Rating
- Downloads
- 34
- Created
- Jan 15, 2025
- Updated
- Mar 28, 2025
- Resources
- 1
- State
Approved
This bundle is marked as recommended. It works and satisfies the submission rules.
General
Import & Config
Code
Changelog
Purpose
This system is meant to be (or become) a complete event system for healing.
Based on Bribe's Heal Event for GUI, it is able to detect native heals and regeneration, but provides more tools for triggered healing and associated events.
This system will avoid recursive calls and will postpone any triggered heal created during events, avoiding variables conflicts.
Events List
Game - PreHealEvent Becomes Equal to 1.00 - Triggered heal only - This event fires when a heal is created, but not yet applied. Use this event to apply any modifiers you want. Depending of your config, PreHealEvent can be 2.00, 3.00 etc., several distinct steps before applying the heal to have a clear separation of modifiers.
Game - AfterHealEvent Becomes Equal to 1.00 - Native and Triggered heal - This event runs when a healed has been applied.
Game - AfterHealEvent Becomes Equal to 0.50 - Regen HP - This event runs when HP regen (excluding HP regen from heroes strength) is detected.
Game - ZeroHealEvent Becomes Equal to 1.00 - Triggered heal only - This event fires when healing amount is too small.
Game - OverHealEvent Becomes Equal to 1.00 - Triggered heal only - This event runs when applied healing was more than target's missing HP.
Game - NegativeHealEvent Becomes Equal to 1.00 - Triggered heal only, needs ALLOW_NEGATIVE_HEALING set to true in config - This event runs when heal become negative during PreHealEvent, thus dealing damage.
Available variables
HealSource - Who casted the heal. Native heal and regen might have this to null (no unit), depending on your config.
HealTarget - Who is being healed.
HealAmount - How much healing is being done at the current step
HealBaseAmount - Initial healing amount, before any modification. This variable should be treated as readonly.
HealPrvAmount - Healing amount at the start of this step. This variable should be treated as readonly.
EffectiveHealAmount - How much healing was done. Access this in AfterHealEvent and/or in OverHealEvent.
OverHealAmount - When OverHealEvent is fired, use this to know how much overhealing have been done. Access this in AfterHealEvent and/or in OverHealEvent.
IsSelfHeal - Is the caster healing himself ?
How to heal using this system ?
To heal a unit using this system, you can either :
1/ Directly use this engine function
Code:
call Heal.HealUnit(source, target, amount)2/ you can set 3 variables and run Heal Unit Trigger. GUI users, I've got your back
-
Set NextHealSource = the one doing the healing
-
Set NextHealTarget = the unit being healed
-
Set NextHealAmount = the amount to be healed
-
Trigger - Run Heal Unit <gen> (ignoring conditions)
Requirements
No requirement is only using triggered healing without HealDetection system to catch native healing & regen.
For HealDetection system:
Mandatory - Bribe's GUI Unit Indexer
Optional & - Bribe's Damage Engine 5.A.0 and Bribe's GUI Unit Event
Import
Make sure to have option "File > Preference > Automatically create unknown variables while pasting trigger data" checked.
If you do not have the requirements in your map yet, copy and paste the "Requirements" folder.
Copy the folder Heal Engine and paste it in your map.
Configuration
The following constant can be configured in the globals section of the HealEngine library.
USE_HEAL_DETECTION - Default: true - Enable/disable HealDetection triggers. If set to true, make sure to have Unit Indexer requirement
HEAL_THRESHOLD - Default: 5.00 - Minimum value for a hp change to be considered a heal worth triggering an event.
HEAL_CHECK_INTERVAL - Default: 0.05 - How often is healing checked.
REGEN_STRENGTH_VALUE - Default: 0.05 - How much HP regen 1 point of strength give to a hero. Should reflect gameplay constant.
REGEN_THRESHOLD - Default: 5.00 - Minimum value to be considered a regen worth triggering an event.
REGEN_EVENT_INTERVAL - Default: 1.00 - How often HP regen is checked.
IS_NATIVE_HEALING_SELF - Default: false - Should native healing be considered as self healing ?
IS_NATIVE_REGEN_SELF - Default: true - Should native HP regen be considered as self healing ?
The following booleans are there to get more control on which units the HealDetection system should keep track of.
IGNORE_LOCUST - Default: true - Ignore units with locust ability (ex: dummies)
IGNORE_STRUCTURE - Default: false - Ignore structures (unit classification must be consistent)
IGNORE_MECHANICAL - Default: false - Ignore mechanical (unit classification must be consistent)
IGNORE_SUMMONED - Default: false - Ignore summoned units (unit classification must be consistent)
IGNORE_HERO - Default: false - Ignore heroes
IGNORE_NON_HERO - Default: false - Ignore every units except heroes
Parameters for the events:
ZEROHEAL_THRESHOLD - Default: 1.00 - Healing with an amount inferior to this value will trigger a ZeroHealEvent.
OVERHEAL_THRESHOLD - Default: 1.00 - Healing with an overheal superior to this value will trigger an OverHealEvent
MAX_PREHEAL_EVENTS - Default: 2.00 - How many PreHealEvent will fire before applying the heal, to make sure modifiers are applied in a correct order. By default, 2 steps (1.00 for percentage multipliers & 2.00 for flat modifiers).
ALLOW_NEGATIVE_HEALING - Default: false - If true, negative healing after PreHealEvents will do damage. Else, heal won't go under 0.
NEGATIVE_HEAL_THRESHOLD - Default: -1.00 - Used only if ALLOW_NEGATIVE_HEALING = true. Threshold for firing NegativeHealEvent.
Complete engine code:
vJASS:
/*
vJass HealEngine 1.0.3
by Marchombre
Requirement if using HealDetection: GUI Unit Indexer 1.4.0.0 (by Bribe)
*/
/*
==================
==== Jass API ====
==================
// This struct is used for native healing and regen detection
struct HealDetection
// Add unit (by its index) to the detection system
static method AddUnit takes integer unitId returns nothing
// Remove unit (by its index) from the detection system
static method SystemRemoveUnit takes integer unitId returns nothing
// Used for Optionnal trigger
// Force a check on target unit. Used before applying damage.
static method Adjust takes unit target returns nothing
// Used for Optionnal trigger
// Adjust values after taking damage, or some events might not trigger due to HP diff
static method AdjustAfterDamage takes unit target, real dmg returns nothing
// Adjust values after receiving a triggered heal, to avoid triggering the healing event a second time by detection
static method AdjustAfterHeal takes unit u, real heal returns nothing
// This struct is used for triggered healing and complete Heal Events
struct Heal
// User Entry Point. Takes heal source, target and amount
// If an other heal is currently running, postpon new one to avoid conflicts
static method HealUnit takes unit source, unit target, real amount
*/
library HealEngine
globals
/*
Variables used for detecting war3 native heals and regeneration
*/
private constant boolean USE_HEAL_DETECTION = true // Enable/disable HealDetection triggers. If set to true, make sure to have Unit Indexer requirement
private constant real HEAL_THRESHOLD = 5.00
private constant real HEAL_CHECK_INTERVAL = 0.05
private constant real REGEN_STRENGTH_VALUE = 0.05
private constant real REGEN_THRESHOLD = 5.00
private constant real REGEN_EVENT_INTERVAL = 1.00
private constant boolean IS_NATIVE_HEALING_SELF = false // True: native healing will be considered selfhealing. False: considered from an unknown source
private constant boolean IS_NATIVE_REGEN_SELF = true // True: regen will be considered selfhealing. False: considered from an unknown source
// Booleans to control control what type of units should be ignored by the HealDetection system.
private constant boolean IGNORE_LOCUST = true // Units with locust ability (ex: dummies)
private constant boolean IGNORE_STRUCTURE = false // Structures (unit classification must be consistent)
private constant boolean IGNORE_MECHANICAL = false // Mechanical (unit classification must be consistent)
private constant boolean IGNORE_SUMMONED = false // Summoned units (unit classification must be consistent)
private constant boolean IGNORE_HERO = false // Heroes
private constant boolean IGNORE_NON_HERO = false // Every units except heroes
/*
Config for Events
*/
private constant real ZEROHEAL_THRESHOLD = 1.00 // Heal under this value will fire ZeroHealEvent
private constant real OVERHEAL_THRESHOLD = 1.00 // How much overheal is needed to fire OverHealEvent
private constant real MAX_PREHEAL_EVENTS = 4.00 // PreHealEvent will fire this many time. Useful if you want to make sure modifiers are applierd if the right order (% then flat for example).
private constant boolean ALLOW_NEGATIVE_HEALING = false // If true, negative healing after PreHealEvents will do damage. Else, heal won't go under 0.
private constant real NEGATIVE_HEAL_THRESHOLD = -1.00 // Used if ALLOW_NEGATIVE_HEALING = true. Threshold for firing NegativeHealEvent.
endglobals
// GUI vars for those who really don't want to call custom script
// These are set before running a trigger calling this engine
/*
unit udg_NextHealSource
unit udg_NextHealTarget
real udg_NextHealAmount
*/
// GUI Vars to catch events
/*
// Variables you can access to get infos on current heal
unit udg_HealSource
unit udg_HealTarget
real udg_HealAmount // Current heal amount
real udg_HealBaseAmount // Heal amount before any event was fired.
real udg_HealPrvAmount // Heal amount at the start of this event
real udg_EffectiveHealAmount // How much HPs was actually healed
real udg_OverHealAmount // How much heal is left after getting the unit to full HP.
boolean udg_IsSelfHeal
// Events variables
real udg_PreHealEvent // Can be 0.00 or X.00, with 1 <= X <= MAX_PREHEAL_EVENTS
real udg_AfterHealEvent // Can be 0.00 or 1.00 or 0.50
real udg_ZeroHealEvent // Can be 0.00 or 1.00
real udg_OverHealEvent // Can be 0.00 or 1.00
real udg_NegativeHealEvent // Can be 0.00 or 1.00
*/
struct HealDetection
private static trigger checkLoopTrigger
private static trigger addUnitTrigger
private static trigger removeUnitTrigger
private static boolean array isInSystem
private static integer array indices
private static integer array indexRef
private static real array lastLife
private static real array regen
private static real array regenBuildUp
private static real array regenTimeLeft
private static integer count = 0
private static integer unitIndex = 0
private static timer healTimer
static method AddUnit takes integer unitId returns nothing
// if Unit is already in system or unit match one ignore config, then do nothing
if isInSystem[unitId] /*
*/ or (GetUnitAbilityLevel(udg_UDexUnits[unitId], 'Aloc') > 0 and IGNORE_LOCUST)/*
*/ or (IsUnitType(udg_UDexUnits[unitId], UNIT_TYPE_MECHANICAL) and IGNORE_MECHANICAL) /*
*/ or (IsUnitType(udg_UDexUnits[unitId], UNIT_TYPE_STRUCTURE) and IGNORE_STRUCTURE) /*
*/ or (IsUnitType(udg_UDexUnits[unitId], UNIT_TYPE_SUMMONED) and IGNORE_SUMMONED) /*
*/ or (IsUnitType(udg_UDexUnits[unitId], UNIT_TYPE_HERO) and IGNORE_HERO) /*
*/ or (not IsUnitType(udg_UDexUnits[unitId], UNIT_TYPE_HERO) and IGNORE_NON_HERO) /*
*/ then
return
endif
set isInSystem[unitId] = true
set indices[count] = unitId
set indexRef[unitId] = count
set lastLife[unitId] = GetWidgetLife(udg_UDexUnits[unitId])
set regenTimeLeft[unitId] = REGEN_EVENT_INTERVAL
set count = count +1
// If first unit added, turn on checkloop
if count == 1 then
call EnableTrigger(checkLoopTrigger)
endif
endmethod
static method SystemRemoveUnit takes integer unitId returns nothing
// If unit not in system, can't remove them, so just returns
if not isInSystem[unitId] then
return
endif
set isInSystem[unitId] = false
set count = count -1
set indices[indexRef[unitId]] = indices[count]
set indexRef[indices[count]] = indexRef[unitId]
// If last unit in system, turn off checkloop
if count == 0 then
call DisableTrigger(checkLoopTrigger)
endif
endmethod
private static method CheckLoop takes nothing returns nothing
local integer max = count -1
local integer unitIndex = 0
local unit target
local real unitHP
local real diff
local real heal
loop
exitwhen unitIndex > max
set unitIndex = indices[unitIndex]
set target = udg_UDexUnits[unitIndex]
set unitHP = GetWidgetLife(target)
set diff = unitHP - lastLife[unitIndex]
set lastLife[unitIndex] = unitHP
set heal = diff - RMaxBJ(0.00, regen[unitIndex])
if heal > HEAL_THRESHOLD then
// Set Up variables
set udg_HealAmount = heal
set udg_HealTarget = target
if IS_NATIVE_HEALING_SELF then
set udg_HealSource = target
else
set udg_HealSource = null // Can't know the source of a native healing sadly
endif
set udg_IsSelfHeal = IS_NATIVE_HEALING_SELF
// Fire AfterHealEvent
set udg_AfterHealEvent = 0.00
set udg_AfterHealEvent = 1.00
set udg_AfterHealEvent = 0.00
else
// Check Regen
set regen[unitIndex] = (regen[unitIndex] + diff) * 0.5
set regenBuildUp[unitIndex] = regenBuildUp[unitIndex] + diff
set regenTimeLeft[unitIndex] = regenTimeLeft[unitIndex] - HEAL_CHECK_INTERVAL
if regenTimeLeft[unitIndex] <= 0.00 then
// reset clock
set regenTimeLeft[unitIndex] = REGEN_EVENT_INTERVAL
set heal = regenBuildUp[unitIndex]
set regenBuildUp[unitIndex] = 0.00
set diff = heal
// Ignore regen from hero stats
if IsUnitType(target, UNIT_TYPE_HERO) then
set diff = diff - REGEN_STRENGTH_VALUE * I2R(GetHeroStr(target, true))
endif
// Fire Regen Event (AfterHealEvent = 0.5)
if diff > REGEN_THRESHOLD then
// Set Up variables
set udg_HealAmount = heal
set udg_HealTarget = target
if IS_NATIVE_REGEN_SELF then
set udg_HealSource = target
else
set udg_HealSource = null // Can't know the source of a native healing sadly
endif
set udg_IsSelfHeal = IS_NATIVE_REGEN_SELF
// Fire AfterHealEvent
set udg_AfterHealEvent = 0.00
set udg_AfterHealEvent = 0.50
set udg_AfterHealEvent = 0.00
endif
endif
endif
set unitIndex = indexRef[unitIndex]
set unitIndex = unitIndex +1
endloop
endmethod
// Check unit new life and fire AfterHealEvent if needed
static method Adjust takes unit target returns nothing
local integer index = GetUnitUserData(target)
local real u_hp = GetWidgetLife(target)
local real heal = u_hp - lastLife[index] - regen[index] * TimerGetElapsed(healTimer) / HEAL_CHECK_INTERVAL
if heal > HEAL_THRESHOLD then
set lastLife[index] = lastLife[index] + heal
// Set Up variables
set udg_HealAmount = heal
set udg_HealTarget = target
if IS_NATIVE_HEALING_SELF then
set udg_HealSource = target
else
set udg_HealSource = null // Can't know the source of a native healing sadly
endif
set udg_IsSelfHeal = IS_NATIVE_HEALING_SELF
// Fire AfterHealEvent
set udg_AfterHealEvent = 0.00
set udg_AfterHealEvent = 1.00
set udg_AfterHealEvent = 0.00
endif
endmethod
// Adjust values when unit takes damage, or heal might not be detected
static method AdjustAfterDamage takes unit target, real dmg returns nothing
local integer index = GetUnitUserData(target)
local real u_hp = GetWidgetLife(target)
if dmg > 0 then
set lastLife[index] = u_hp - regen[index] * TimerGetElapsed(healTimer) / HEAL_CHECK_INTERVAL
else
call Adjust(target)
endif
endmethod
// Adjust after heal, avoiding a double event for one heal
static method AdjustAfterHeal takes unit u, real heal returns nothing
local integer index = GetUnitUserData(u)
set lastLife[index] = lastLife[index] + heal
endmethod
private static method ActionAddUnit takes nothing returns nothing
call AddUnit(udg_UDex)
endmethod
private static method ActionRemoveUnit takes nothing returns nothing
call SystemRemoveUnit(udg_UDex)
endmethod
private static method onInit takes nothing returns nothing
if USE_HEAL_DETECTION then
set healTimer = CreateTimer()
set checkLoopTrigger = CreateTrigger()
set addUnitTrigger = CreateTrigger()
set removeUnitTrigger = CreateTrigger()
call StartTimerBJ(healTimer, true, HEAL_CHECK_INTERVAL)
call TriggerRegisterTimerExpireEvent(checkLoopTrigger, healTimer)
call TriggerAddAction(checkLoopTrigger, function HealDetection.CheckLoop)
call TriggerRegisterVariableEvent(addUnitTrigger, "udg_UnitIndexEvent", EQUAL, 1.00)
call TriggerRegisterVariableEvent(addUnitTrigger, "udg_DeathEvent", EQUAL, 2.00)
call TriggerAddAction(addUnitTrigger, function HealDetection.ActionAddUnit)
call TriggerRegisterVariableEvent(removeUnitTrigger, "udg_UnitIndexEvent", EQUAL, 2.00)
call TriggerRegisterVariableEvent(removeUnitTrigger, "udg_DeathEvent", EQUAL, 0.50)
call TriggerRegisterVariableEvent(removeUnitTrigger, "udg_DeathEvent", EQUAL, 1.00)
call TriggerRegisterVariableEvent(removeUnitTrigger, "udg_DeathEvent", EQUAL, 3.00)
call TriggerAddAction(removeUnitTrigger, function HealDetection.ActionRemoveUnit)
endif
endmethod
endstruct
struct Heal
/*
Variables used in healing
*/
private unit healSource
private unit healTarget
private real healBaseAmt
private real healPrevAmt
private real healAmount
private real effectiveHealAmt
private real overHealAmount
private boolean isSelfHeal
/*
Variables used for listing
*/
private Heal next
private static Heal first
private static Heal last
private static method create takes unit source, unit target, real amount returns Heal
local Heal this = Heal.allocate()
set this.healSource = source
set this.healTarget = target
set this.healAmount = amount
set this.healBaseAmt = amount
set this.healPrevAmt = amount
set this.isSelfHeal = (source == target)
set this.overHealAmount = 0
set this.effectiveHealAmt = 0
set this.next = 0
return this
endmethod
private method destroy takes nothing returns nothing
call this.deallocate()
endmethod
private static method onInit takes nothing returns nothing
set first = 0
set last = 0
endmethod
/*
Entry point for user.
*/
static method HealUnit takes unit source, unit target, real amount returns nothing
local Heal h = Heal.create(source, target, amount)
if first == 0 then
set first = h
set last = h
call Heal.Run()
else
set last.next = h
set last = last.next
endif
endmethod
// Put this instance members into GUI variables
private method setEventVariables takes nothing returns nothing
set udg_HealSource = this.healSource
set udg_HealTarget = this.healTarget
set udg_HealAmount = this.healAmount
set udg_HealBaseAmount = this.healBaseAmt
set udg_HealPrvAmount = this.healPrevAmt
set udg_EffectiveHealAmount = this.effectiveHealAmt
set udg_OverHealAmount = this.overHealAmount
set udg_IsSelfHeal = this.isSelfHeal
endmethod
// Updates this instance members with GUI vars that might have been updated
private method getEventVariables takes nothing returns nothing
set this.healSource = udg_HealSource
set this.healTarget = udg_HealTarget
set this.healAmount = udg_HealAmount
set this.healPrevAmt = udg_HealAmount // Stores this step result for reference in next step if needed.
set this.isSelfHeal = (this.healSource == this.healTarget)
endmethod
// Reset Variables to a neutral state
private static method resetEventVariables takes nothing returns nothing
set udg_HealSource = null
set udg_HealTarget = null
set udg_HealBaseAmount = 0.00
set udg_HealPrvAmount = 0.00
set udg_HealAmount = 0.00
set udg_EffectiveHealAmount = 0.00
set udg_OverHealAmount = 0.00
set udg_IsSelfHeal = false
endmethod
/*
Function where the healing and Events are done.
Healing are dealt one at the time. Healing created during Events will be postponed.
*/
private static method Run takes nothing returns nothing
local Heal h
local integer u_custom
local real u_current_hp
local real u_max_hp
local real u_missing_hp
local real new_missing_hp
local real i = 1.00
loop
exitwhen first == null
set h = first
// Using not == instead of !=; the idea is to eliminate floating point bugs when two numbers are very close to 0,
// because JASS uses a less-strict comparison for checking if a number is equal than when it is unequal.
if not (h.healAmount == 0.00) then
loop
exitwhen i > MAX_PREHEAL_EVENTS
// Set GUI vars
call h.setEventVariables()
// Fire PreHealEvent
set udg_PreHealEvent = 0.00
set udg_PreHealEvent = i
set udg_PreHealEvent = 0.00
// Update fields in case event was caught and variables changed.
call h.getEventVariables()
set i = i +1.00
endloop
if not ALLOW_NEGATIVE_HEALING and h.healAmount < 0.00 then
set h.healAmount = 0.00
endif
// Get target infos
set u_custom = GetUnitUserData(h.healTarget)
set u_max_hp = GetUnitState(h.healTarget, UNIT_STATE_MAX_LIFE)
set u_current_hp = GetWidgetLife(h.healTarget)
set u_missing_hp = u_max_hp - u_current_hp
if h.healAmount > 0 then
// Healing itself.
call SetWidgetLife(h.healTarget, u_current_hp + h.healAmount)
// Getting new missing hp
set new_missing_hp = GetUnitState(h.healTarget, UNIT_STATE_MAX_LIFE) - GetWidgetLife(h.healTarget)
// Computing effective healing and possible overhealing
set h.effectiveHealAmt = new_missing_hp - u_missing_hp
set h.overHealAmount = h.healAmount - h.effectiveHealAmt
else
// Use Damage function to be compatible with damage engines
call UnitDamageTargetBJ(h.healSource, h.healTarget, h.healAmount, ATTACK_TYPE_MAGIC, DAMAGE_TYPE_MAGIC)
set h.effectiveHealAmt = h.healAmount
endif
// Fire OverHealEvent
if h.overHealAmount > OVERHEAL_THRESHOLD then
// Set GUI vars
call h.setEventVariables()
set udg_OverHealEvent = 0.00
set udg_OverHealEvent = 1.00
set udg_OverHealEvent = 0.00
endif
// Fire AfterHealEvent if enough healing was done, else ZeroHealEvent
if h.effectiveHealAmt > ZEROHEAL_THRESHOLD or (h.overHealAmount > 0.00) then
// Update HealDetection system, avoiding the event triggering twice for this heal
call HealDetection.AdjustAfterHeal(h.healTarget, h.healAmount)
// Set GUI vars
call h.setEventVariables()
set udg_AfterHealEvent = 0.00
set udg_AfterHealEvent = 1.00
set udg_AfterHealEvent = 0.00
elseif h.effectiveHealAmt < NEGATIVE_HEAL_THRESHOLD then
// Set GUI vars
call h.setEventVariables()
set udg_NegativeHealEvent = 0.00
set udg_NegativeHealEvent = 1.00
set udg_NegativeHealEvent = 0.00
else
// Set GUI vars
call h.setEventVariables()
set udg_ZeroHealEvent = 0.00
set udg_ZeroHealEvent = 1.00
set udg_ZeroHealEvent = 0.00
endif
endif
// Resets variables
call resetEventVariables()
// Set the next heal that will be run
set first = h.next
// Free resources
call h.destroy()
endloop
endmethod
endstruct
endlibraryVersion 1.0.3 (2025-02-10)
New/Changed config options:
USE_HEAL_DETECTION - Default: true - Enable/disable HealDetection triggers. If set to true, make sure to have Unit Indexer requirement
IS_NATIVE_HEALING_SELF - Default: false - Should native healing be considered as self healing ?
IS_NATIVE_REGEN_SELF - Default: true - Should native HP regen be considered as self healing ?
ALLOW_NEGATIVE_HEALING - Default: false - If true, negative healing after PreHealEvents will do damage. Else, heal won't go under 0.
NEGATIVE_HEAL_THRESHOLD - Default: -1.00 - Used only if ALLOW_NEGATIVE_HEALING = true. Threshold for firing NegativeHealEvent.
New Event:
Game - NegativeHealEvent Becomes Equal to 1.00 - Triggered heal only, needs ALLOW_NEGATIVE_HEALING set to true in config - This event runs when heal become negative during PreHealEvent, thus dealing damage.
New/Changed variables:
HealBaseAmount - Initial healing amount, before any modification. This variable should be treated as readonly.
HealPrvAmount - Healing amount at the start of this step. This variable should be treated as readonly.
EffectiveHealAmount - How much healing was done. Access this in AfterHealEvent and/or in OverHealEvent.
USE_HEAL_DETECTION - Default: true - Enable/disable HealDetection triggers. If set to true, make sure to have Unit Indexer requirement
IS_NATIVE_HEALING_SELF - Default: false - Should native healing be considered as self healing ?
IS_NATIVE_REGEN_SELF - Default: true - Should native HP regen be considered as self healing ?
ALLOW_NEGATIVE_HEALING - Default: false - If true, negative healing after PreHealEvents will do damage. Else, heal won't go under 0.
NEGATIVE_HEAL_THRESHOLD - Default: -1.00 - Used only if ALLOW_NEGATIVE_HEALING = true. Threshold for firing NegativeHealEvent.
New Event:
Game - NegativeHealEvent Becomes Equal to 1.00 - Triggered heal only, needs ALLOW_NEGATIVE_HEALING set to true in config - This event runs when heal become negative during PreHealEvent, thus dealing damage.
New/Changed variables:
HealBaseAmount - Initial healing amount, before any modification. This variable should be treated as readonly.
HealPrvAmount - Healing amount at the start of this step. This variable should be treated as readonly.
EffectiveHealAmount - How much healing was done. Access this in AfterHealEvent and/or in OverHealEvent.
Version 1.0.2 (2025-01-23)
I thought it would be nice to get a bit more control on the HealDetection system.
Added a bunch of constant that will allow to ignore some types of units:
IGNORE_LOCUST - Default: true - Ignore units with locust ability (ex: dummies)
IGNORE_STRUCTURE - Default: false - Ignore structures (unit classification must be consistent)
IGNORE_MECHANICAL - Default: false - Ignore mechanical (unit classification must be consistent)
IGNORE_SUMMONED - Default: false - Ignore summoned units (unit classification must be consistent)
IGNORE_HERO - Default: false - Ignore heroes
IGNORE_NON_HERO - Default: false - Ignore every units except heroes
Added a bunch of constant that will allow to ignore some types of units:
IGNORE_LOCUST - Default: true - Ignore units with locust ability (ex: dummies)
IGNORE_STRUCTURE - Default: false - Ignore structures (unit classification must be consistent)
IGNORE_MECHANICAL - Default: false - Ignore mechanical (unit classification must be consistent)
IGNORE_SUMMONED - Default: false - Ignore summoned units (unit classification must be consistent)
IGNORE_HERO - Default: false - Ignore heroes
IGNORE_NON_HERO - Default: false - Ignore every units except heroes
Version 1.0.1 (2025-01-19)
- Changed condition for ZeroHealEvent & AfterHealEvent to use struct members and not globals variables.
- Added the possibility to fire more than one PreHealEvent with new parameter MAX_PREHEAL_EVENTS if you need more steps to separate different modifiers.
Version 1.0.0 (2025-01-15)
First upload.
Keywords:
heal, healing, heal event, heal engine, EVENT_PLAYER_UNIT_HEALED
Contents
Reviews
- Joined
- Nov 18, 2014
- Messages
- 81
Version 1.0.1 :
- Changed condition for ZeroHealEvent & AfterHealEvent to use struct members and not globals variables.
- Added the possibility to fire more than one PreHealEvent with new parameter MAX_PREHEAL_EVENTS if you need more steps to separate different modifiers.
- Joined
- Nov 18, 2014
- Messages
- 81
I thought it would be nice to get a bit more control on the HealDetection system
Version 1.0.2
Added a bunch of constant that will allow to ignore some types of units:
IGNORE_LOCUST - Default: true - Ignore units with locust ability (ex: dummies)
IGNORE_STRUCTURE - Default: false - Ignore structures (unit classification must be consistent)
IGNORE_MECHANICAL - Default: false - Ignore mechanical (unit classification must be consistent)
IGNORE_SUMMONED - Default: false - Ignore summoned units (unit classification must be consistent)
IGNORE_HERO - Default: false - Ignore heroes
IGNORE_NON_HERO - Default: false - Ignore every units except heroes
Version 1.0.2
Added a bunch of constant that will allow to ignore some types of units:
IGNORE_LOCUST - Default: true - Ignore units with locust ability (ex: dummies)
IGNORE_STRUCTURE - Default: false - Ignore structures (unit classification must be consistent)
IGNORE_MECHANICAL - Default: false - Ignore mechanical (unit classification must be consistent)
IGNORE_SUMMONED - Default: false - Ignore summoned units (unit classification must be consistent)
IGNORE_HERO - Default: false - Ignore heroes
IGNORE_NON_HERO - Default: false - Ignore every units except heroes
- Joined
- Oct 11, 2021
- Messages
- 88
I'm curious to see how you develop it, it will have many great uses if perfected.
- Joined
- Nov 18, 2014
- Messages
- 81
Feel free to make suggestions
I have currently added everything I said "Damn, I wish I could do that" for.
I'm pretty sure there are others uses I didn't even think of yet, and I'll do my best to add them if someone point them out
Otherwise, I'll wait until a new need rise in the map I'm currently maintaining
- Joined
- Jan 30, 2013
- Messages
- 12,761
How does the MaxPreHeal event works in detail? I think there can be room for spells that 'interrupt' any healing and cancel their effect completely, or spells that only selectively negate certain heals
- Joined
- Nov 18, 2014
- Messages
- 81
MAX_PREHEAL_EVENTS is a config constant, not an event in itself.
It dictates how many PreHealEvents are fired before applying the heal.
For example, with MAX_PREHEAL_EVENTS = 1, you will have only PreHealEvent = 1.00
With MAX_PREHEAL_EVENTS = 5, you'll get PreHealEvent =1.00, PreHealEvent = 2.00, PreHealEvent = 3.00, PreHealEvent = 4.00 & PreHealEvent =5.00
It is possible to completely negate a heal.
For example, I'm currently using this system with 4 PreHealEvents:
- PreHealEvent = 1.00 -- flat heal increase
- PreHealEvent = 2.00 -- % heal increase
- PreHealEvent = 3.00 -- % heal reduction
- PreHealEvent = 4.00 -- flat heal reduction
Having healing reduction after any heal increase will allow you to give a 100% heal reduction and negate the heal entirely.
This part is quite limited for now. You can only do a threshold (like every heal < 100 will be negated), or check if the unit is self healing with IsSelfHeal.
Feel free to correct me I misunderstood you, and suggest improvements
Last edited:
Spell Reviewer
- Joined
- Dec 13, 2009
- Messages
- 983
Healing through code is so much better than these dirty hacks required to detect native heals, so that is a welcome addition to the Heal Detection system. Since it is possible to use the system without using any native heals, you should make an option to disable that feature (and remove the unit indexer requirement if possible).
I think overheal is poorly handled. Instead of having a separate event, I think there should be just the heal event which sets the variables Raw Heal, Effective Heal, and Overheal. In any case, even if you keep the separate overheal event, an effective heal variable should exist.
I didn't find any problems with the code and all of the features seem to be working without problems.
Approved
I think overheal is poorly handled. Instead of having a separate event, I think there should be just the heal event which sets the variables Raw Heal, Effective Heal, and Overheal. In any case, even if you keep the separate overheal event, an effective heal variable should exist.
I didn't find any problems with the code and all of the features seem to be working without problems.
Approved
- Joined
- Nov 18, 2014
- Messages
- 81
Thanks for the approval
This should be enough, as long I clearly state that unit indexer is required if config allows native heals detection.
However, I agree that EffectiveHeal is missing and will add that in next version
If user catch PreHealEvent and apply heal reduction superior to the heal amount, the system would damage the unit and would still trigger events.
I'll probably add a config option to decide if negative healing should damage the target or act as a 0 heal. And will use a proper damaging function so damage engines can catch it.
Might add a NegativeHealEvent too ?
Not sure of that yet.
That's a good idea. I guess I could just put a condition in the onInit of HealDetection struct and avoid creating the triggers/timers for native heals.
This should be enough, as long I clearly state that unit indexer is required if config allows native heals detection.
OverHealEvent was, in my opinion, like ZeroHealEvent. An event for convenience and trigger clarity, more that mandatory thing to have. Way easier - in my mind at least - to code and read "Check OverHealEvent = 1.00" than "Check if AfterHealEvent = 1.00 and OverHealAmount > 0.00", especially when using GUI.
However, I agree that EffectiveHeal is missing and will add that in next version
Well, as a matter of fact, I did find one problem myself
If user catch PreHealEvent and apply heal reduction superior to the heal amount, the system would damage the unit and would still trigger events.
I'll probably add a config option to decide if negative healing should damage the target or act as a 0 heal. And will use a proper damaging function so damage engines can catch it.
Might add a NegativeHealEvent too ?
Not sure of that yet.
- Joined
- Aug 6, 2015
- Messages
- 786
Would you add LUA version as well? (might come in handy for people that make the map on LUA - even for GUI users)
- Joined
- Nov 18, 2014
- Messages
- 81
I haven't looked into lua yet, so not planned right now.
I might try in the future, but will not be my priority. And I'll probably wait to have a version stable enough so I don't have to duplicate every single change
Spell Reviewer
- Joined
- Dec 13, 2009
- Messages
- 983
Variable events do not work in Lua, so the entire system would have to be rewritten.
- Joined
- Nov 18, 2014
- Messages
- 81
Version 1.0.3
New/Changed config options:
USE_HEAL_DETECTION - Default: true - Enable/disable HealDetection triggers. If set to true, make sure to have Unit Indexer requirement
IS_NATIVE_HEALING_SELF - Default: false - Should native healing be considered as self healing ?
IS_NATIVE_REGEN_SELF - Default: true - Should native HP regen be considered as self healing ?
ALLOW_NEGATIVE_HEALING - Default: false - If true, negative healing after PreHealEvents will do damage. Else, heal won't go under 0.
NEGATIVE_HEAL_THRESHOLD - Default: -1.00 - Used only if ALLOW_NEGATIVE_HEALING = true. Threshold for firing NegativeHealEvent.
New Event:
Game - NegativeHealEvent Becomes Equal to 1.00 - Triggered heal only, needs ALLOW_NEGATIVE_HEALING set to true in config - This event runs when heal become negative during PreHealEvent, thus dealing damage.
New/Changed variables:
HealBaseAmount - Initial healing amount, before any modification. This variable should be treated as readonly.
HealPrvAmount - Healing amount at the start of this step. This variable should be treated as readonly.
EffectiveHealAmount - How much healing was done. Access this in AfterHealEvent and/or in OverHealEvent.
New/Changed config options:
USE_HEAL_DETECTION - Default: true - Enable/disable HealDetection triggers. If set to true, make sure to have Unit Indexer requirement
IS_NATIVE_HEALING_SELF - Default: false - Should native healing be considered as self healing ?
IS_NATIVE_REGEN_SELF - Default: true - Should native HP regen be considered as self healing ?
ALLOW_NEGATIVE_HEALING - Default: false - If true, negative healing after PreHealEvents will do damage. Else, heal won't go under 0.
NEGATIVE_HEAL_THRESHOLD - Default: -1.00 - Used only if ALLOW_NEGATIVE_HEALING = true. Threshold for firing NegativeHealEvent.
New Event:
Game - NegativeHealEvent Becomes Equal to 1.00 - Triggered heal only, needs ALLOW_NEGATIVE_HEALING set to true in config - This event runs when heal become negative during PreHealEvent, thus dealing damage.
New/Changed variables:
HealBaseAmount - Initial healing amount, before any modification. This variable should be treated as readonly.
HealPrvAmount - Healing amount at the start of this step. This variable should be treated as readonly.
EffectiveHealAmount - How much healing was done. Access this in AfterHealEvent and/or in OverHealEvent.
- Joined
- Feb 5, 2018
- Messages
- 567
A very useful system seems to work without causing any issues.
seems to work without causing any issues.
